MSC21X152Z502: DescriptionSafety Chip Capacitors; File Size321KB，4 Pages; ManufacturerMeritek Electronics; Websitehttp://www.meritekusa.com

Download Datasheet View All

MSC21X152Z502 Overview

Safety Chip Capacitors

Preview

Download Datasheet

View All

Safety

Chip Capacitors

MSC

Series

(X1Y2/X2Y3)

MERITEK

UL No. E

EATURES

High reliability

and

stability

Small

size

and

high capacitance

RoHS compliant

Safety

standard

approval

by UL60950

PECIFICATIONS

Dielectric

Size

Rated voltage (WVDC)

Capacitance range*

X1Y2 Class

X2Y3 Class

Cap5pF

5pF<Cap<10pF

Cap10pF

NP0

1808, 1812

250Vac

3pF ~ 470pF

3pF ~ 1000pF

MERITEK

MSC

series safety Chip Capacitors are

designed

for

surge or lightning protection in

across the line and line bypass applications,

such as telephone, computer network, modem,

and other electronic equipments.

X7R

1808, 1812, 2211

250Vac

X1Y2 Class

X2Y3 Class

100pF ~ 2200pF

150pF ~ 4700pF

Capacitance tolerance

Tan *

Cap<30pF

Cap30pF

100G

: B (±0.1pF), C (±0.25pF)

: C (±0.25pF), D (±0.5pF)

: F (±1%), G (±2%), J (±5%),

K (±10%)

: D.F1/(400+20C)

: D.F0.10%

10G

-55 to +125°C

±30ppm /

J (±5%), K (±10%), M (±20%)

2.5%

or R

C500 -F whichever is smaller

Insulation resistance at 500Vdc for 60 seconds

Operating temperature

Capacitance characteristic

Termination

or R

C1000 whichever is smaller

±15%

Ag/Ni/Sn (lead-free termination)

* NP0: Apply 1.0±0.2Vrms, 1.0MHz±10%, at 25°C ambient temperature

X7R: Apply 1.0±0.2Vrms, 1.0kHz±10%, at 25°C ambient temperature.

ART

UMBERING

YSTEM

Meritek

Series

Size

Code

1808

1812

2211

MSC

101

Dielectric

CODE

NPO

8R2

8.2

Tolerance

±1%

±10%

302

X2Y3

502

X1Y2

Rev 7

X7R

101

100

0.0001

Code

102

1000

0.001

Tolerance

±2%

±20%

152

1500

1.5

0.0015

Code

Tolerance

±5%

+80/-20%

Capacitance

CODE

μF

Tolerance

Code

Rated Voltage
