High Voltage Ceramic
Capacitors 500V-4KV
S
PECIFICATIONS
Operating
Temperature
Temperature
Characteristic
Capacitance
SL and Y5P: -30
o
C to +85
o
C
Z5U and Z5V: +10
o
C to +85
o
C
SL: P350 to N1000
Y5P: ±10%
Z5U: +22/-56%
Z5V: +22/-82%
SL: Measured at 1 ±0.1MHz, 1Vrms max. at 25
o
C
Y5P, Z5U and Z5V: Measured at 1 ±0.1KHz, 1Vrms max.
at 25
o
C
500VDC to 4000VDC
SL: <30pF >400 + 20
o
C min., =30pF >1000
Y5P and Z5U: 2.5% max. Z5V: 5.0% max.
500V: 250% rated voltage
1000V to 4000V: 150% rated voltage
10,000 Mega ohms min. at 500VDC 60 sec. charging
500V to 2000V phenolic or epoxy resin coating
=
3000V epoxy resin (94V-0)
HV
Series
MERITEK
Rated voltage
Quality and
dissipation factor
Tested voltage
Insulation resistance
Coating material
P
ART
N
UMBERING
S
YSTEM
HV
High voltage series
Temperature characteristics
Capacitance
CODE
1R5
1.5pF
330
33pF
201
200pF
202
2000pF
333
.033μF
104
0.1μF
Y5P
471
K
2KV
6
B
1
Capacitance tolerance
CODE
C
D
J
K
M
S
Z
P
Tolerance
±0.25pF
±0.5pF
±5%
±10%
±20%
+50/-20%
+80/-20%
+100/-0%
Applicable T.C.
NPO-N750
NPO-N750
NPO-N1500
NPO-N1500, Y5E, Y5P
NPO-N1500, Y5E, Y5P, Z5U
Z5U
Z5U, Z5V
Z5U, Z5V
Available Capacitances
0.5pF-5pF
0.5pF-10pF
Over 5pF
Over 10pF
Over 10pF
Over 1000pF
Over 1000pF
Over 1000pF
Rated voltage
Lead spacing
CODE
5
5.08mm
6
6.35mm
7
7.62mm
9
9.52mm
Packaging code
CODE
B
Bulk
R
Tape & Reel
Exposed Disc and
2 Cut Leads
D
F
Tape & Ammo (Flat)
Complete Durez
3 Coverage and Cut Leads
Leads
D
Inside Kink
4 and Cut Leads
D
Outward Kink
5 and Cut Leads
D
Lead type
Complete Durez
1 Coverage Leads
D
P
25.4
(1.00")
max.
P
4.75 0.75
(0.19 .03")
F
F
P
P
4.75 0.75
(0.19 .03")
F
4.75
(0.19
0.75
.03")
F
1
(.04")
min.
4.75
(0.19
P
0.75
.03")
F
2
(.08")
max.
Style 1,2 and 3
500V
1000V 4000V
P=2.0(.078")max
P=3.0(.118")max
F:
F:
0.8(.03")
1.5(.06")
Style 4 and 5
500V
1000V 4000V
P=4.0(.16")max
P=5.0(.197")max
F:
F:
0.8(.03")
1.5(.06")
Specifications are
subject to change without notice.
rev.6b
High Voltage Ceramic
Capacitors 500V-4KV
HV
Series
MERITEK
RATED VOLTAGE
(VDC)
SL
1-33
TEMP CHARACTERISTICS / CAPACITANCE (pF)
Y5P (B)
100-220
330
470
560
680-820
1000
1500
2200
3300
-
4700
Z5U (E)
100-680
820
1000
1500
2200
3300
4700
-
-
10000
15000
1500
2200
3300
4700
-
-
10000
-
15000
Z5V (F)
470-1000
DIMENSIONS (mm)
D max.
8
9
10
12
14
16
18
20
22
24
26
8
0.6
±.05
T
d∅
47-56
68
82-100
120
4000V
150-180
220
270-330
390
470
560-680
SPECIFICATIONS
Temperature Characteristic
Operating Temperature Range
Dissipation Factor (25
o
C, 1KHz)
Insulation Resistance at 25
o
C,
rated voltage (min.)
COG / NPO
0 ±30ppm/ C
-55
o
C to +125
o
C
0.15% max. at 1Vrms
100K Mega ohms or
1000 Mega ohms x
μF
whichever is less
2.5 x Rated Voltage
o
X7R
±15%
-55
o
C to +125
o
C
2.5% max. at 1Vrms
100K Mega ohms or
1000 Mega ohms x
μF
whichever is less
2.5 x Rated Voltage
Z5U
+22/-56%
(+10
o
C to 85
o
C )
+10
o
C to +85
o
C
3.5% max. at 0.5Vrms
10K Mega ohms or
500 Mega ohms x
μF
whichever is less
2.5 x Rated Voltage
Dielectric Withstanding Voltage
(50mA max., 5 sec.)
Life Test (1,000 hours)
2 x Rated Voltage
at +125
o
C
2 x Rated Voltage
at +125
o
C
1.5 x Rated Voltage
at +85
o
C
