Crimp Connector, Board-In Type
DP-30
Series
2.0mm Spacing
Terminal
0.4
■
Features
1. Housing for this connector measures only
4.6mm high and 2.7mm thick.
2. Plugs for connectors in this series are available
in 14 different pin types ranging from 2P to 15P.
3. A lead-free product.
Part No.
Applicable
Electrical
Wire Size
AWG)
Electrical Wire
Sheath Dia.
(mm)
Material
Plating
No. of
Terminal/
Reel
W-T0663-11#01F
22
30
1.5
0.8
■
Specifications
1. Rating : 1A 50V AC/DC
2. Contact Resistance : 20mΩ max.
3. Insulation Resistance : 1000MΩ min. at 500V DC
4. Withstanding Voltage : 500V AC for one minute.
5. Operating Temperature Range : –25˚C to +85˚C
6. Applicable Wire Size : AWG22 to 30
(Sheath dia. ø0.8 to ø1.5mm)
7. Applicable P.C. Board Thickness : 1.2mm to 1.6mm
Phosphor
Bronze
Tinned (Reflow
Treatment)
15,000
Housing
W-D34
-1N#01
No. of Pins
B
A
Part No.
W-D3402-1N#01
W-D3403-1N#01
W-D3404-1N#01
W-D3405-1N#01
W-D3406-1N#01
W-D3407-1N#01
W-D3408-1N#01
W-D3409-1N#01
W-D3410-1N#01
W-D3411-1N#01
W-D3412-1N#01
W-D3413-1N#01
W-D3414-1N#01
W-D3415-1N#01
A
2.0
4.0
6.0
8.0
10.0
12.0
14.0
16.0
18.0
20.0
22.0
24.0
26.0
28.0
B
2.0
±
0.1
(Spacing)
4.8
6.8
8.8
10.8
12.8
14.8
16.8
18.8
20.8
22.8
24.8
26.8
28.8
30.8
C
No. of
Pins
2
3
4
5
6
7
8
9
10
11
12
13
14
15
■
Material and Plating
Housing :
Polyamide (PA), Natural Color, 94V-0
Terminal :
Phosphor Bronze,
Tin Plating (Reflow Treatment)
■
Note
Custom made models will be available upon
request.
C
2.7
1
Pin No.1
■
P.C. Board Dimension
■
Structural Diagram
n
1
2.0
±
0.1
2.7
2.0
±
0.1
(Spacing)
0.8
±
0.05
4.6
3.3
1.55
4.6
Crimp Connectors
7.9
