ADSL LINE TRANSFORMER SURFACE MOUNT MAGNETICS
EN60950 Basic Insulation compliant 250Vrms
SMD compact foot print design
Industrial operating temp: -40ºC to +85ºC
Electrical Specifications @25
o
C
Part
Number
Turns Ratio
(10KHz,0.1V)
16-9:1-4
16-9:5-8
(short 11-14,2-3) (short 11-14,6-7)
1:1 2%
4.29:1 2%
OCL
(10KHz,0.1V)
16-9(short 11-14)
400uH
5%
LL
(100KHz,0.1V)
Cww
(100KHz,0.1V)
16-9( short11-14,1-2-3-4-5-6-7-8) 1-16( short 1-2-3-4-5-6-7-8,11-14)
15uH max
35pF max
Continue
AEP027SI
DCR
16-9
(short 11-14)
1.0
max
1-4
(short 2-3)
2.2
max
5-8
(short 6-7)
0.7
max
THD
)
(20KHz,5.3Vrms
LB
(35KHz~650KHz)
Hi-Pot
VAC
(1mA/2s)
-80dB max
55dB min
3000
All specifications subject to change without notice.
MECHANICAL
14.0max
3.4
5.1
3.4
19.0
14.0
1.0
3.4
ALLIED
AEP027SI
11.9
5.1
3.4
1.7
0.5
SUGGESTED PAD LAYOUT
YYWW
12.7max
1.7
11.9
Units:mm
Unless otherwise specified all tolerances are: 0.25 in mm
16.5max
0.13
12 SURFACES
SCHEMATICS
1
3
16
2
PRI
11
14
4
5
SEC
9
7
6
8
