HI-SINCERITY
MICROELECTRONICS CORP.
Spec. No. : HSMA2009021
Issued Date : 2009.03.05
Revised Date :
Page No. : 1/4
HSMA120
thru
HSMA1100
Schottky Barrier Rectifiers
(Reverse Voltage 20 to 100V, Forward Current 1A)
Features
•
For surface mounted applications
•
Metal-Semiconductor junction with guardrjng
•
Epitaxial construction
•
Very low forward voltage drop
•
High Current Capability
•
Plastic material has UL flammability classification 94V-0
•
For use in low voltage, high frequency inverters free wheeling
And polarity orotection applications
DO-214AC(SMA)
Mechanical Data
•
Package: JEDEC DO-214AC(SMA) molded plastic
•
Polarity: Indicated by cathode band
•
Weight: 0.002 ounce, 0.064 gram
Maximum Ratings & Electrical Characteristics
Ratings at 25°C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load. For capacitive load. Derate current by 20%.
Ratings
Repetitive Peak Reverse Voltage
Surge Peak Reverse Voltage
DC Blocking Voltage
Average Forward Rectified Current (T
L
=100 C)
Peak Forward Surge Current, 50Hz Half
o
Sine-wave (T
A
=25 C)
Instantaneous Forward Voltage
Leakage Current (T
J
=25 C, V
R
=V
RRM
)
Leakage Current (T
J
=100 C, V
R
=V
RRM
)
Typical Junction Capacitance
Thermal Resistance Junction to Lead
Operating Junction Temperature Range
Storage Temperature Range
C
J
R
θ
JL
T
J
T
STG
o
o
o
Symbol
V
RRM
V
RSM
V
DC
I
FAV
I
FSM
V
F
I
R
HSMA HSMA HSMA HSMA HSMA HSMA HSMA HSMA HSMA
120
130
140 150
160
170 180
190
1100
20
14
20
30
21
30
40
28
40
50
35
50
60
42
60
1
30
0.50
0.70
0.5
10.0
110
30
-55 to +125
-55 to +150
5.0
30
25
0.79(0.69@ T
j
=100 C)
o
Unit
V
V
V
A
A
V
mA
mA
pF
30
°C
°C
70
49
70
80
56
80
90
63
90
100
70
100
HSMA120 thru HSMA160
HSMC Product Specification
HI-SINCERITY
MICROELECTRONICS CORP.
DO-214AC(SMA) Dimension
Marking:
Spec. No. : HSMA2009021
Issued Date : 2009.03.05
Revised Date :
Page No. : 4/4
A
B
C
Note:
Green label is used for pb-free packing
DIM
A
B
C
D
E
F
G
H
Min.
1.27
2.40
4.00
1.90
0.80
0.10
4.80
0.15
Max.
1.63
2.65
4.60
2.25
1.50
0.20
5.20
0.31
Unit: mm
D
H
E
F
G
2-Lead DO-214AC(SMA) Plastic
Surface Mounted Package
HSMC Package Code: SMA
Marking:
A
B
C
Note:
Green label is used for pb-free packing
DIM
A
B
C
D
E
F
G
H
Min.
1.27
2.40
4.00
1.90
0.80
0.10
4.80
0.15
Max.
1.63
2.65
4.60
2.25
1.50
0.20
5.20
0.31
Unit: mm
D
H
E
F
G
2-Lead DO-214AC(SMA) Plastic
Surface Mounted Package
HSMC Package Code: SMA
Important Notice:
•
All rights are reserved. Reproduction in whole or in part is prohibited without the prior written approval of HSMC.
•
HSMC reserves the right to make changes to its products without notice.
•
HSMC semiconductor products are not warranted to be suitable for use in Life-Support Applications, or systems.
•
HSMC assumes no liability for any consequence of customer product design, infringement of patents, or application assistance.
