SEMICONDUCTORS
PNP TIP34-A-B-C
SILICON POWER TRANSISTORS
They are PNP power transistors mounted in jedec TO-3PN. They are intended for use in
general purpose power amplifier and switching applications.
NPN complements are TIP33-A-B-C
Compliance to RoHS
.
ABSOLUTE MAXIMUM RATINGS
Symbol
Ratings
TIP34
TIP34A
TIP34B
TIP34C
TIP34
TIP34A
TIP34B
TIP34C
TIP34
TIP34A
TIP34B
TIP34C
TIP34
TIP34A
TIP34B
TIP34C
TIP34
TIP34A
TIP34B
TIP34C
Value
-40
-60
-80
-100
-40
-60
-80
-100
Unit
V
CBO
Collector-Base Voltage
V
V
CEO
Collector-Emitter Voltage
V
V
EBO
Emitter-Base Voltage
-5
V
I
C
Collector Current
-10
A
I
CM
Collector Peak Current
-15
A
02/10/2012
COMSET SEMICONDUCTORS
1|4
SEMICONDUCTORS
PNP TIP34-A-B-C
ABSOLUTE MAXIMUM RATINGS
Symbol
Ratings
TIP34
TIP34A
TIP34B
TIP34C
TIP34
TIP34A
TIP34B
TIP34C
TIP34
TIP34A
TIP34B
TIP34C
TIP34
TIP34A
TIP34B
TIP34C
TIP34
TIP34A
TIP34B
TIP34C
Value
Unit
I
B
Base Current
-3
A
@ T
c
< 25°
P
C
Power Dissipation
@ T
a
< 25°
80
Watts
3.5
T
J
Junction Temperature
150
°C
-65 to +150
T
s
Storage Temperature range
THERMAL CHARACTERISTICS
Symbol
Ratings
TIP34
TIP34A
TIP34B
TIP34C
TIP34
TIP34A
TIP34B
TIP34C
Value
Unit
R
thJ-MB
From junction to mounting base
1.56
°C/W
R
thJ-A
From junction to ambient in free air
35.7
°C/W
02/10/2012
COMSET SEMICONDUCTORS
2|4
SEMICONDUCTORS
PNP TIP34-A-B-C
Symbol
Ratings
Current Gain-Bandwidth
Product
Test Condition(s)
V
CE
= -10 V
I
C
= -0.5 A
f= 1kHz
TIP34
TIP34A
TIP34B
TIP34C
Min
Typ
Max
Unit
f
T
3
-
-
MHz
MECHANICAL DATA CASE TO3PN Non Isolated Plastic Package
DIMENSIONS (mm)
Min.
A
B
C
D
E
F
G
H
J
K
L
M
N
O
P
R
S
T
Pin 1 :
Pin 2 :
Pin 3 :
Case :
15.20
1.90
4.60
3.10
Max.
1600
2.10
5.00
3.30
9.60
2.00
0.55
1.40
5.55
20.20
1.25
2.00
3.00
4.00
4.00
1.80
5.20
Base
Collector
Emitter
Collector
0.35
5.35
20.00
19.60
0.95
4.80
September 2012
Information furnished is believed to be accurate and reliable. However, Comset Semiconductors assumes no responsibility for the consequences of
use of such information nor for any infringement of patents or other rights of third parties which may results from its use. Data are subject to change
without notice. Comset Semiconductors makes no warranty, representation or guarantee regarding the suitability of its products for any particular
purpose, nor does Comset Semiconductors assume any liability arising out of the application or use of any product and specifically disclaims any
and all liability, including without limitation consequential or incidental damages. Comset Semiconductors’ products are not authorized for use as
critical components in life support devices or systems.
www.comsetsemi.com
02/10/2012
