Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207
Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com
Customer Specification
PART NO. 5010/20C
Construction
Diameters (In)
1) Component 1
a) Conductor
b) Insulation
(1) Color Code
Cond
1
2
3
4
5
Color
BLACK
BROWN
RED
ORANGE
YELLOW
20 X 1 COND
22 (7/30) AWG TC
0.010" Wall, Nom. PVC, Semi Rigid
Alpha Wire Color Code E
Cond
8
9
10
11
12
Color
VIOLET
SLATE
WHITE
WHITE/BLACK
WHITE/BROWN
Cond
15
16
17
18
19
Color
WHITE/YELLOW
WHITE/GREEN
WHITE/BLUE
WHITE/VIOLET
WHITE/SLATE
0.030
0.050
6
GREEN
13
WHITE/RED
20
WHITE/BLACK/BROW
N
7
2) Cable Assembly
a) Twists:
b) Core Wrap
3) Jacket
a) Color(s)
b) Ripcord
BLUE
14
20 Components Cabled
4.0 Twists/foot (min)
WHITE/ORANGE
Nonwoven Polyester Tape, 25% Overlap, Min.
0.032" Wall, Nom.,PVC
0.331 (0.349 Max.)
Slate, Black, Yellow, Orange, Blue, Green, Red, Sand Beige, White
1 End 810 Denier Nylon
ALPHA WIRE-* P/N 5010/20C 20C 22 AWG
XTRAGUARD(R) 1 (UL) TYPE CM 105C OR AWM 2464 VW-1
c) Print
--- LLXXXXXX CSA 105C TYPE CMG FT4 CE
ROHS (SEQ FOOTAGE)
* = Factory Code
[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]
Applicable Specifications
1) UL
a) Component 1
b) Overall
AWM/STYLE 10002
AWM/STYLE 2464
CM
VW-1
2) CSA International
CMG
FT4
3) CE:
EU Low Voltage Directive 2006/95/EC
105°C
105°C / 300 VRMS
80°C / 300 VRMS
105°C
Environmental
1) EU Directive 2002/95/EC(RoHS):
All materials used in the manufacture of this part are in compliance with EU Directive
2002/95/EU regarding the restriction of use of certain hazardous substances in electrical and
electronic equipment. Consult Alpha Wire's web site for compliance Date of Manufacture.
2) REACH Regulation (EC 1907/2006):
This product does not contain Substances of Very High Concern (SVHC) listed on the European
Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information,
please see Alpha's REACH SVHC Declaration.
3) California Proposition 65:
The outer surface materials used in the manufacture of this part meet the requirements of
California Proposition 65.
Properties
Physical & Mechanical Properties
1) Temperature Range
2) Bend Radius
3) Pull Tension
4) Sunlight Resistance
Electrical Properties
1) Voltage Rating
2) Capacitance
3) Inductance
4) Conductor DCR
-30 to 105°C
10X Cable Diameter
110 Lbs, Maximum
Yes
(For Engineering purposes only)
300 VRMS
23.5 pf/ft @1 kHz, Nominal Conductor to Conductor
0.18 µH/ft, Nominal
16.6 /1000ft @20°C, Nominal
Other
Packaging
a) 1000 FT
b) 500 FT
c) 100 FT
d) Bulk(Made-to-order)
[Spool dimensions may vary slightly]
Flange x Traverse x Barrel (inches)
18 x 12 x 8 Continuous length
12 x 12 x 3.5 Continuous length
10 x 4 x 3.5 Continuous length
www.alphawire.com
Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207
Tel: 1-800-52 ALPHA (25742)
Although Alpha Wire (“Alpha”) makes every reasonable effort to ensure there accuracy at the time of publication, information and specifications
described herein are subject to errors or omissions and to changes without notice, and the listing of such information and specifications does not
ensure product availability.
Alpha provides the information and specifications herein on an “AS IS” basis, with no representations or warranties, whether express, statutory or
implied. In no event will Alpha be liable for any damages (including consequential, indirect, incidental, special, punitive, or exemplary) whatsoever,
even if Alpha had been advised of the possibility of such damages, whether in an action under contract, negligence or any other theory, arising out
of or in connection with the use, or inability to use, the information or specifications described herein.
Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207
Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com
RoHS CERTIFICATE OF COMPLIANCE
To Whom It May Concern:
Alpha Wire Part Number:5010/20C
5010/20C , RoHS-Compliant Commencing With8/1/2005Production
This document certifies that the Alpha part numbers cited above are manufactured in accordancewith Directive 2002/95/EC of the European
Parliament and of the Council of 27 January 2003,better known as the RoHS Directives, with regards to restrictions of the use of certain
hazardoussubstances used in the manufacture of electrical and electronic equipment. The reader is referredto these Directives for the specific
definitions and extents of these Directives.
No Exemptions arerequired for RoHS Compliance on this item.
Substance
Lead
Mercury
Cadmium
Hexavalent Chromium
Polybrominated Biphenyls (PBB)
Polybrominated Diphenyl Ethers (PBDE)
Including Deca-BDE
Maximum Control Value
0.1% by weight (1000 ppm)
0.1% by weight (1000 ppm)
0.01% by weight (100 ppm)
0.1% by weight (1000 ppm)
0.1% by weight (1000 ppm)
0.1% by weight (1000 ppm)
The information provided in this document and disclosure is correct to the best of Alpha Wire'sknowledge, information and belief at the date of its
release. The information provided is designedonly as a general guide for the safe handling, storage, and any other operation of the productitself or
the one that it will become part of. The intent of this document is not to be considered awarranty or quality specification. Regulatory information is
for guidance purposes only. Productusers are responsible for determining the applicability of legislation and regulations based ontheir individual
usage of the product.
Authorized Signatory for the Alpha Wire Company:
Dave Watson, Director of Engineering & QA
11/19/2012
