3
コイン型ポリアセンキャパシタ
COIN TYPE PAS CAPACITOR
TYPE
OPERATING TEMP.
HR
TR, SR
Operating temp. range
−20∼＋60℃
−25∼＋70℃
特長 FEATURES
・
高容量 高信頼性
・
PASはそのアモルファス構造に多くのイオンを蓄える
ドーピングする）
（
ことが
できるため、従来の電気二重層コンデンサと比較すると大きな容量を有して
います。またPASは極めて安定した素材であり、サイ
クル寿½、過充電・過
放電などの耐久性に優れています。
・RoHS/WEEE指令対応
すべての½品においてRoHS指令の対応を完了しています。リチウムイオン二
次電池のような回収・
リサイ
クルの義務はありません。
・
世界最小
外径3.8mm×厚さ1.1mmの世界最小サイズのコイン型キャパシタ
「PAS311シ
リーズ」
を開発しました。薄膜電極材料の開発や特殊処理耐熱性ガスケッ
ト
の採用、封止技術の開発により最小化を実現しました。
・½電圧化対応
携帯電話やP
D Aなどの高機½化に伴う内部回路の½電圧化において、2.0V
以下の充放電特性に優れた
「PAS414TR」
を開発しました。薄膜電極材料の
改良により、従来比で容量20%アップを実現しました。様々な内部回路電圧
に最適な½品を取り揃えています。
・High
capacity / High reliability
PAS can store a large number of ions into its amorphous structure
（dop-
ing）therefore PAS capacitor has much larger capacity than conventional
,
electric double layer capacitor. In addition, PAS is extremely stable ma-
terial and PAS capacitor shows excellent performance of cycle life and
durability to overcharge and overdischarge.
・RoHS
/ WEEE compliance
PAS capacitors are RoHS and WEEE compliant products and have no
recycling and collection duty that is required in lithium ion battery’ case.
s
・
The world’ smallest capacitor
s
“PAS311
series” the world’ smallest coin shaped capacitors, which size
is
s
is diameter
3.8mm
×
height
1.1mm.
This smallest product was carried out by developing electrode materials,
sealing technology and introducing special processed heat resistance gas-
ket.
・Low
voltage compliance
Shoei Electronics developed PAS414TR, which has high performance
in charging/discharging characteristics with lower than
2.0V
setting,
in response to low voltage trend for multifunctional mobile phone
and PDAs. PAS414TR achieved
20%
increase of capacity compared
with our conventional line up by improving electrode. We have vari-
ous types of products suitable for various internal circuit voltages.
用途 APPLICATIONS
・携帯電話、デジタルカメ
ラ、携帯情報端末
（PDA）
、携帯ラジオなどのメモリーや
時計機½
（RTC）
バックアッ
プ用電源
・Memory
and RTC back-up power source used for cellular phone, PDA,
digital camera, portable radio and so on.
½名表記法 ORDERING
CODE
1
シリーズ名
PAS
ポリアセンキャパシタ
3
厚み寸法 H(mm)
09
0.9
11
1.1
14
1.4
5
共通記号
-
固定
6
端子½状
VA5
個別仕様
VA5R
個別仕様
VA6R
個別仕様
VE5
個別仕様
VE5R
個別仕様
2
外径寸法 φD(mm)
3
3.8
4
4.8
4
最大½用電圧
（V）／はんだ付け
TR
2.0
鉛フリー リフローはんだ付け
SR
2.5 2.6*）
鉛フリー リフローはんだ付け
（
HR
3.3
鉛フリー リフローはんだ付け
（*）
：PAS311SRのみ
P A S 3 1 1 H R - V A 6 R
1
1
Series name
PAS
Polyacene Capacitors
2
3
3
4
5
6
5
Common sign
-
Fixation
Height H(mm)
09
0.9
11
1.1
14
1.4
6
Lead Terminal
VA5 Individually specified
VA5R Individually specified
VA6R Individually specified
VE5 Individually specified
VE5R Individually specified
2
Diameter φD(mm)
3
3.8
4
4.8
4
Maximum Usable Voltage V）／Soldering
（
TR
2.0
Lead Free Reflow Soldering
SR
2.5(2.6*)
Lead Free Reflow Soldering
HR
3.3
Lead Free Reflow Soldering
（*）
：PAS311SR
only
496
！
「½社½品に関するお断り」
を必ずお読みください。
△
½社カタログをご½用の際には
9
！
△
Please read the "Notice for TAIYO YUDEN products" before using this catalog.
