NC7SVL08 — TinyLogic
®
Low-I
CCT
Two-Input AND Gate
December 2010
NC7SVL08
TinyLogic
®
Low-I
CCT
Two-Input AND Gate
Features
0.9V to 3.6V V
CC
Supply Operation
3.6V Over-Voltage Tolerant I/Os at V
CC
from
0.9V to 3.6V
Power-Off High-Impedance Inputs and Outputs
Proprietary Quiet Series™ Noise / EMI Reduction
Circuitry
Ultra-Small MicroPak™ Packages
Ultra-Low Dynamic Power
Description
The NC7SVL08 is a single two-input AND gate with a
low-I
CCT
input design from Fairchild’s Ultra-Low Power
®
(ULP-A) series of TinyLogic . The NC7SVL08 features
very low quiescent current, even when the input voltage
is lower than the V
CC
supply. This feature services
mobile handset applications very well, allowing for direct
interface with baseband processor general-purpose
I/Os. Since mobile devices rely on a battery supply, the
NC7SVL08 facilitates lower power consumption in
mixed-voltage rail environments.
This product is designed on an advanced CMOS
technology for a wide low-voltage operating range (0.9V
to 3.6V V
CC
), high drive needs (up to 24mA), and speed
(maximum propagation delay of 3.5ns, V
CC
=3.3V). It
achieves this performance while maintaining low CMOS
power dissipation.
Ordering Information
Part Number
NC7SVL08P5X
NC7SVL08L6X
NC7SVL08FHX
Top Mark
L08
CE
CE
Package
5-Lead SC70, EIAJ SC-88a, 1.25mm Wide
6-Lead MicroPak™, 1.00mm Wide
6-Lead, MicroPak2™, 1x1mm Body, .35mm Pitch
Packing Method
3000 Units on
Tape & Reel
5000 Units on
Tape & Reel
5000 Units on
Tape & Reel
© 2008 Fairchild Semiconductor Corporation
NC7SVL08 • Rev. 1.0.5
www.fairchildsemi.com
NC7SVL08 — TinyLogic
®
Low-I
CCT
Two-Input AND Gate
Absolute Maximum Ratings
Stresses exceeding the absolute maximum ratings may damage the device. The device may not function or be
operable above the recommended operating conditions and stressing the parts to these levels is not recommended.
In addition, extended exposure to stresses above the recommended operating conditions may affect device
reliability. The absolute maximum ratings are stress ratings only.
Symbol
V
CC
V
IN
V
OUT
I
IK
I
OK
I
OH
/ I
OL
I
CC
or I
GND
T
STG
T
J
T
L
P
D
Supply Voltage
DC Input Voltage
DC Output Voltage
DC Input Diode Current
DC Output Diode Current
Parameter
Min.
-0.5
-0.5
Max.
4.6
4.6
V
CC
to +0.5
4.6
-50
-50
+50
±50
±50
Unit
V
V
V
V
mA
mA
mA
mA
°C
°C
°C
mW
HIGH or LOW State
V
CC
=0V
V
IN
< 0V
V
OUT
< 0V
V
OUT
> V
CC
(1)
-0.5
-0.5
DC Output Source/Sink Current
DC V
CC
or Ground Current per Supply Pin
Storage Temperature Range
Junction Temperature Under Bias
Junction Lead Temperature (Soldering, 10 Seconds)
SC70-5
Power Dissipation at +85°C
Human Body Model
Charged Device Model
MicroPak™-6
MicroPak2™-6
JEDEC: JESD22-A114
JEDEC: JESD22-C101
-65
+150
+150
+260
150
130
120
4000
2000
ESD
V
Note:
1. The I
O
maximum rating must be observed.
Recommended Operating Conditions
The Recommended Operating Conditions table defines the conditions for actual device operation. Recommended
operating conditions are specified to ensure optimal performance to the datasheet specifications. Fairchild does not
recommend exceeding them or designing to Absolute Maximum Ratings.
Symbol
V
CC
V
IN
V
OUT
Parameter
Supply Voltage
Input Voltage
(2)
Conditions
Min.
0.9
0
Max.
3.6
3.6
V
CC
3.6
±24.0
±18.0
±6.0
±4.0
±2.0
±0.1
Unit
V
V
V
Output Voltage
HIGH or LOW State
V
CC
=0V
V
CC
=3.0V to 3.6V
V
CC
=2.3V to 2.7V
V
CC
=1.65V to 1.95V
V
CC
=1.40V to 1.60V
V
CC
=1.10V to 1.30V
V
CC
=0.9V
0
0
I
OH
/ I
OL
Output Current in I
OH
/ I
OL
mA
µA
°C
ns/V
°C/W
T
A
Δt
/
ΔV
θ
JA
Free Air Operating Temperature
Minimum Input Edge Rate
Thermal Resistance
V
IN
=0.8V to 2.0V, V
CC
=3.0V
SC70-5
MicroPak™-6
MicroPak2™-6
-40
+85
10
425
500
560
Note:
2. Unused inputs must be held HIGH or LOW. They may not float.
© 2008 Fairchild Semiconductor Corporation
NC7SVL08 • Rev. 1.0.5
www.fairchildsemi.com
3
