UNISONIC TECHNOLOGIES CO., LTD
U74LVC86A
QUAD 2-INPUT EXCLUSIVE
OR GATE
DESCRIPTION
CMOS IC
The
U74LVC86A
is a quad 2-input exclusive OR gate
which performs the function Y=A
B
or
Y=AB
AB
. It is
designed for 1.2V to 3.6V operation.
FEATURES
* Wide supply voltage range from 1.2V to 3.6V
* Max t
pd
of 4.6ns at C
L
=50pF, V
CC
=3.3V
* Up to 5.5V inputs accept voltages
* Low power consumption, I
CC
= 1
μA
(Max.)
* Compatible with TTL families
ORDERING INFORMATION
Ordering Number
U74LVC86AG-S14-R
U74LVC86AG-P14-R
Package
SOP-14
TSSOP-14
Packing
Tape Reel
Tape Reel
MARKING
www.unisonic.com.tw
Copyright © 2014 Unisonic Technologies Co., Ltd
1 of 6
QW-R502-783.B
U74LVC86A
PIN CONFIGURATION
CMOS IC
F PIN DESCRIPTION
PIN
1, 4, 9, 12
2, 5, 10, 13
3, 6, 8, 11
7
14
SYMBOL
1A-4A
1B-4B
1Y-4Y
GND
V
CC
FUNCTION
Data inputs
Data inputs
Data outputs
Ground (0V)
Positive supply voltage
FUNCTION TABLE
(EACH GATE)
INPUTS
A
L
L
H
H
B
L
H
L
H
OUTPUT
Y
L
H
H
L
LOGIC SYMBOL
(ONE GATE)
LOGIC DIAGRAM
(ONE GATE)
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
2 of 6
QW-R502-783.B
U74LVC86A
ABSOLUTE MAXIMUM RATING
(T
A
=25°C , unless otherwise specified)
PARAMETER
CMOS IC
SYMBOL
TEST CONDITIONS
UNIT
Supply Voltage
V
CC
-0.5 ~ 6.5
V
Input Voltage
V
IN
-0.5 ~ 5.5
V
Output Voltage (any output in the high or low state)
V
OUT
-0.5 ~ +V
CC
+0.5
V
Input Clamp Current
I
IK
-50
mA
Output Clamp Current
I
OK
-50
mA
Output Current
I
OUT
±50
mA
V
CC
or GND Current
I
CC
±100
mA
Power Dissipation
T
A
=-40°C to +125°C
P
D
500
mW
Storage Temperature
T
STG
-65 ~ +150
°C
Notes: 1. The input and output voltage ratings may be exceeded if the input and output current ratings are observed.
2. Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
THERMAL DATA
SYMBOL
θ
JA
RATING
115
UNIT
°C/W
PARAMETER
Junction to Ambient
RECOMMENDED OPERATING CONDITIONS
PARAMETER
SYMBOL
V
CC
TEST CONDITIONS
Max. speed performance
Low-voltage applications
V
CC
= 1.2V
V
CC
= 1.65V ~ 1.95V
V
CC
= 2.3V ~ 2.7V
V
CC
= 2.7V ~ 3.6V
V
CC
= 1.2V
V
CC
= 1.65V ~ 1.95V
V
CC
= 2.3V ~ 2.7V
V
CC
= 2.7V ~ 3.6V
MIN
2.7
1.2
V
CC
0.65 × V
CC
1.7
2.0
MAX
3.6
3.6
UNIT
V
Supply Voltage
High-Level Input Voltage
V
IH
V
GND
0.35 × V
CC
0.7
0.8
5.5
V
CC
20
10
+85
Low-Level Input Voltage
Input Voltage
Output Voltage
Input Transition Rise or Fall Rate
Operating Temperature
V
IL
V
IN
V
OUT
t/v
T
A
V
V
V
ns/V
°C
0
0
V
CC
=1.2 ~ 2.7V
V
CC
=2.7 ~ 3.6V
-40
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
3 of 6
QW-R502-783.B
U74LVC86A
ELECTRICAL CHARACTERISTICS
PARAMETER
SYMBOL
TYP
TEST CONDITIONS
MIN
I
OH
= -100μA, V
CC
= 1.65V ~ 3.6V
V
CC
- 0.2
V
I
= V
IH
or V
IL
I
OH
= -4mA, V
CC
= 1.65V
1.29
V
I
= V
IH
or V
IL
I
OH
= -8mA, V
CC
= 2.3V
1.9
V
I
= V
IH
or V
IL
High-Level Output Voltage
V
OH
I
OH
= -12mA, V
CC
= 2.7V
2.2
V
I
= V
IH
or V
IL
I
OH
= -18mA, V
CC
= 3.0V
2.4
V
I
= V
IH
or V
IL
I
OH
= -24mA, V
CC
= 3.0V
2.3
V
I
= V
IH
or V
IL
I
OH
= 100μA, V
CC
= 1.65V ~ 3.6V
V
I
= V
IH
or V
IL
I
OH
= 4mA, V
CC
= 1.65V,
V
I
= V
IH
or V
IL
I
OH
= 8mA, V
CC
= 2.3V,
Low-Level Output Voltage
V
OL
V
I
= V
IH
or V
IL
I
OH
= 12mA, V
CC
= 2.7V,
V
I
= V
IH
or V
IL
I
OH
= 24mA, V
CC
= 3.0V,
V
I
= V
IH
or V
IL
V
IN
= 5.5V or GND,
Input Leakage Current
I
I(LEAK)
V
CC
= 3.6V
V
IN
= V
CC
or GND, I
OUT
= 0,
Quiescent Supply Current
I
CC
V
CC
= 3.6V
One input at V
CC
– 0.6V,
Additional quiescent Supply
other inputs at V
CC
or GND,
I
CC
Current
I
OUT
= 0, V
CC
= 2.7V ~ 3.6V
Input Capacitance
C
IN
V
IN
= V
CC
or GND, V
CC
=3.3V
Note: 1. All typical values are at V
CC
= 3.3 V, T
A
= 25 °C
CMOS IC
MAX
UNIT
V
V
CC
0.1
0.24
0.3
0.4
0.55
±0.1
0.1
5
5.0
±1
1
500
μA
μA
μA
pF
V
SWITCHING CHARACTERISTICS
PARAMETER
SYMBOL
MIN
1
1
1
1
TYP
11
4.1
2.9
2.8
2.5
MAX UNIT
9.4
7.1
5.4
4.4
TEST CONDITIONS
V
CC
= 1.2V, C
L
= 50 pF, R
L
= 500Ω
V
CC
= 1.8V ±0.15V, C
L
= 30 pF, R
L
= 1KΩ
Propagation delay from input
t
PLH
/t
PHL
V
CC
= 2.5V ±0.2V, C
L
= 50 pF, R
L
= 500Ω
(A or B) to output (Y)
V
CC
= 2.7V, C
L
= 50 pF, R
L
= 500Ω
V
CC
= 3.3 ±0.3V, C
L
= 30pF, R
L
= 500Ω
Note: 1. All typical values are at V
CC
= 3.3 V, T
A
= 25 °C
ns
OPERATING CHARACTERISTICS
SYMBOL
TEST CONDITIONS
C
pd
V
CC
= 3.3V
TYP
28
UNIT
pF
PARAMETER
Power Dissipation Capacitance Per Gate
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
4 of 6
QW-R502-783.B
U74LVC86A
TEST CIRCUIT AND WAVEFORMS
CMOS IC
TEST
t
PLH
/t
PHL
S1
Open
V
CC
1.8V
2.5V
2.7V
3.3V
Input
V
IN
V
CC
V
CC
2.7V
3.3V
t
R
, t
F
≤2ns
≤2ns
≤2.5ns
≤2.5ns
V
M
V
CC
/2
V
CC
/2
1.5V
1.5V
V
LOAD
2 × V
CC
2 × V
CC
6V
6V
C
L
30pF
50pF
50pF
50pF
R
L
1KΩ
500Ω
500Ω
500Ω
V
IN
Input
V
M
V
M
0V
t
PLH
t
PHL
V
OH
Output
VM
V
M
V
OL
t
PHL
t
PLH
V
OH
Output
VM
V
M
V
OL
Notes: 1. C
L
includes probe and jig capacitance.
2. All input pulses are supplied by generators having the following characteristics: PRR
≤10MHz,
Z
O
= 50Ω.
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
5 of 6
QW-R502-783.B
