TC62D723FNAG
TOSHIBA CDMOS Integrated Circuit Silicone Monolithic
TC62D723FＮAG
16-Output constant current LED driver with the output gain control function and the PWM grayscale function
1.Feature
The TC62D723FNAG is LED drivers which have the sink-type
constant current output.
The output gain control function of 8-bit and the PWM grayscale
function of 16, 14, 12, and 10-bit are built into this IC.
Output current value of 16 channels is set by one external
resistance.
In addition, the thermal shutdown function, the output open
detection function, and the output short detection function are built
in.
This IC is most suitable for lighting the LED module and the display.
TC62D723FNAG
P-SSOP24-0409-0.64-001
Weight
P-SSOP24-0409-0.64-001:0.14g(Typ.)
2.Characteristics
•
Supply voltage
: V
DD
=
3.0 to 5.5 V
•
16-output built-in
•
Output current setup range
: I
OUT
=
1.5 to 90 mA
•
Constant current output accuracy
(@ R
EXT
= 1.2 kΩ, V
OUT
= 1.0 V, V
DD
= 3.3 V, 5.0 V)
: S rank；Between outputs
±
1.5 % (max)
: S rank；Between devices:
±
1.5 % (max)
: N rank；Between outputs
±
2.5 % (max)
: N rank；Between devices:
±
2.5 % (max)
•
Output voltage
: V
OUT
=
17 V (MAX)
•
I/O interface
: CMOS interfaces (Input of a schmitt trigger)
•
Data transfer frequency
: f
SCK
=
30 MHz (MAX)
•
PWM frequency
: f
PWM
=
33 MHz (MAX)
•
Operation temperature range
: T
opr
= −40
to 85
°C
•
8-bit (256 steps) output gain control function built-in.
•
PWM grayscale function built-in. (PWM resolution is selectable)
16-bit (65536 steps), 14-bit (16384 steps)
12-bit (4096 steps), 10-bit (1024 steps)
Selection of teh one-shot output PWM mode or the repeat PWM output mode is possible.
•
Thermal shutdown function (TSD) built-in.
•
Output error detection function built-in.
This function has the automatic operation and the command
input manual operation.
Output open detection function (OOD) and output short
detection function (OSD) built-in.
•
Power-on-reset function built-in. (When the power supply is turned on, internal data is reset)
•
Stand-by function built-in. (I
DD
=1μA at standby mode)
•
Output delay function built-in. (Output switching noise is reduced)
•
Package
: P-SSOP24-0409-0.64-001
For detailed part naming conventions, contact your local Toshiba sales representative or distributor.
1
2012-01-30
TC62D723FNAG
5.Pin Description
Pin No.
Pin Name
I/O
Function
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
GND
SIN
SCK
TRANS
OUT0
⎯
The ground pin.
The serial data input pin.
The serial data transfer clock input pin.
The data transfer command input pin.
The sink type constant current output pin.
The sink type constant current output pin.
The sink type constant current output pin.
The sink type constant current output pin.
The sink type constant current output pin.
The sink type constant current output pin.
The sink type constant current output pin.
The sink type constant current output pin.
The sink type constant current output pin.
The sink type constant current output pin.
The sink type constant current output pin.
The sink type constant current output pin.
The sink type constant current output pin.
The sink type constant current output pin.
The sink type constant current output pin.
The sink type constant current output pin.
The reference clock input pin for PWM grayscale control.
One cycle of the input clock becomes a minimum pulse width of the PWM output.
The serial data output pin.
The constant current value setting resistor connection pin.
The power supply input pin.
I
I
I
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
I
O
⎯
OUT1
OUT2
OUT3
OUT4
OUT5
OUT6
OUT7
OUT8
OUT9
OUT10
OUT11
OUT12
OUT13
OUT14
OUT15
PWMCLK
SOUT
REXT
VDD
I
4
2012-01-30
