Wireless - Cellular Products
Type N - High Power - 500 Watts
•
•
•
•
Wireless Frequency Bands
PCS and Cellular applications
Type N, TNC, & 7-16 Connector Interface
High Performance
Couplers
Midwest Microwave offers this complete series of high perfor-
mance Directional Couplers using Type N, TNC and 7-16 connector
interfaces. They are ruggedly constructed using high power circuits
that exhibit excellent VSWR and directivity performance in the 500
Watt power category. They are offered in most of the popular
wireless PCS and Cellular frequency bandwidths.
Case Style 1, 2, 3 & 4
Electrical Specifications
Frequency
R an g e
(MH z )
C ase
Style
Model N umber
C oupling
Frequency
Sensitivity
Insertion
L o ss
(dB )
0.20
0.20
0.20
0.20
0.20
0.20
0.25
0.22
0.20
0.20
0.20
0.20
0.25
0.22
0.20
D irectivity
(dB )
VSWR
(max)
Input
Avg
(W)
200
500
500
200
500
500
200
500
500
200
500
500
200
500
500
Note: Thickness will be
1.38 (35.1) for Models
with 7-16 Connectors
P o w er
R efl
Avg
(W)
50
500
500
50
500
500
50
500
500
50
500
500
50
500
500
P eak
(kW)
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
1
500 - 1000
1
2
1
800 - 980
1
2
3
1000 - 2000
3
4
3
1700 - 2200
3
4
3
2000 - 4000
3
4
C PW-5140-10-N N N -05
C PW-5140-20-N N N -05
C PW-5140-30-N N N -05
C PW-5141-10-N N N -05
C PW-5141-20-N N N -05
C PW-5141-30-N N N -05
C PW-5142-10-N N N -05
C PW-5142-20-N N N -05
C PW-5142-30-N N N -05
C PW-5143-10-N N N -05
C PW-5143-20-N N N -05
C PW-5143-30-N N N -05
C PW-5144-10-N N N -05
C PW-5144-20-N N N -05
C PW-5144-30-N N N -05
10 + 0.5
20 + 0.5
30 + 0.5
10 + 0.3
20 + 0.3
30 + 0.3
10 + 1.0
20 + 1.0
30 + 1.0
10 + 0.5
20 + 0.5
30 + 0.5
10 + 1.0
20 + 1.0
30 + 1.0
+ 0.50
+ 0.50
+ 0.50
+ 0.15
+ 0.20
+ 0.20
+ 0.75
+ 0.75
+ 0.75
+ 0.20
+ 0.20
+ 0.30
+ 0.75
+ 0.75
+ 0.75
20
20
20
20
20
20
30
30
30
25
27
27
25
27
27
1.20
1.20
1.20
1.20
1.20
1.20
1.15
1.15
1.15
1.10
1.10
1.10
1.15
1.15
1.15
Note:
For "TNC" or "7-16" connector interfaces, substitute "TNC" or "716" for "NNN" in Model Number.
C ase
Style
1
2
A
11.58 (294.13)
11.58 (294.13)
B
3.00 (76.2)
3.00 (76.2)
C
0.88 (22.4)
0.69 (17.5)
Weight
Oz (K g)
36 (1.0)
36 (1.0)
C ase
Style
3
4
A
4.10 (104.1)
4.10 (104.1)
B
1.09 (27.7)
1.09 (27.7)
C
0.88 (22.4)
0.69 (17.5)
Weight
Oz (K g)
18 (0.5)
18 (0.5)
