NLSF3T125

Quad Bus Buffer

with 3−State Control Inputs

The NLSF3T125 is a high speed CMOS quad bus buffer fabricated

with silicon gate CMOS technology. It achieves high speed operation

similar to equivalent Bipolar Schottky TTL while maintaining CMOS

low power dissipation.

The NLSF3T125 requires the 3−state control input (OE) to be set

High to place the output into the high impedance state.

The T125 inputs are compatible with TTL levels. This device can be

used as a level converter for interfacing 3.3 V to 5.0 V, because it has

full 5.0 V CMOS level output swings.

The NLSF3T125 input structures provide protection when voltages

between 0 V and 5.5 V are applied, regardless of the supply voltage.

The output structures also provide protection when V

= 0 V. These

input and output structures help prevent device destruction caused by

supply voltage

−

input/output voltage mismatch, battery backup, hot

insertion, etc.

The internal circuit is composed of three stages, including a buffer

output which provides high noise immunity and stable output. The

inputs tolerate voltages up to 7.0 V, allowing the interface of 5.0 V

systems to 3.0 V systems.

Features

http://onsemi.com

QFN−16

CASE 485G

MARKING DIAGRAM

NLSF3

T125

ALYWG

NLSF3T125

= Specific Device Code

= Assembly Location

= Wafer Lot

= Year

= Work Week

= Pb−Free Package

•

High Speed: t

= 3.8 ns (Typ) at V

= 5.0 V

Low Power Dissipation: I

= 4.0

(Max) at T

= 25°C

TTL−Compatible Inputs: V

= 0.8 V; V

= 2.0 V

Power Down Protection Provided on Inputs

Balanced Propagation Delays

Designed for 2.0 V to 5.5 V Operating Range

Low Noise: V

OLP

= 0.8 V (Max)

Pin and Function Compatible with Other Standard Logic Families

Latchup Performance Exceeds 300 mA

ESD Performance: Human Body Model; > 2000 V,

Machine Model; > 200 V

•

Chip Complexity: 72 FETs or 18 Equivalent Gates

•

These Devices are Pb−Free and are RoHS Compliant

FUNCTION TABLE

NLSF3T125

Inputs

Output

(Note: Microdot may be in either location)

ORDERING INFORMATION

Device

Package

Shipping

†

NLSF3T125MNR2G QFN−16 3000/Tape & Reel

(Pb−Free)

†For information on tape and reel specifications,

including part orientation and tape sizes, please

refer to our Tape and Reel Packaging Specifications

Brochure, BRD8011/D.

Semiconductor Components Industries, LLC, 2011

June, 2011

−

Rev. 5

Publication Order Number:

NLSF3T125/D
