Subminiature ceramic couplers (suited to SMT)
HD-S Series
sFeatures
1.Subminiature design
Hirose Electric's expertise in miniaturization and
matching technology has permitted a subminiature,
lightweight design.
HD-19003S
HD-21503S
2.High performance
The high frequency characteristics feature
extremely low loss and a high degree of matching
which makes these couplers ideal for a wide variety
of wireless phone base station applications.
3.Suited to Automatic Mounting
HD-15003S
HD-09003S
HD-20003SH
Embossed tape packaging permits automatic
mounting.(Individual delivery can also be
accommodated.)
sProduct
specifications
Rating
Frequency range (NOTE)
Characteristic impedance
Maximum usable power (NOTE)
800 to 2300 MHz
50ø
10 to 50 W
Operating temperature range
Operating relative humidity
_10ç
to
+65ç
95% or less
NOTE: The frequency range and the maximum usable power will differ depending on the model.
Item
1.Insulation resistance 1000 Mø min.
Standard
Conditions
Measured at 100 V DC
Frequency of 10 to 500 Hz, overall amplitude of 1.52 mm,
98 m/s
2
acceleration, in 3 axial directions, 2 hours each
980 m/s
2
acceleration, half sine wave, in 3 axial directions,
3 times each
(_55ç: 30 min.
¡
5 to 35ç: Within 15 min.
¡
85ç: 30 min.
¡
5 to 35ç: Within 15min.) for 200 cycles
2.Vibration resistance No electrical disconnections of 1µs or greater
Contact resistance: 1000 mø max.
No damage, cracks, or parts looseness
3.Shock resistance
No electrical disconnections of 1µs or greater
Contact resistance: 1000 mø max.
No damage, cracks, or parts looseness
4.Temperature cycle Contact resistance: 1000 mø or less
Insulation resistance: 1000 Mø min.
No damage, cracks, or parts loosenes
qThe
test method conforms to MIL-STD-202.
sMaterials
Part
Case
Material
Ceramic
Processing
Solder plating
sRecommended
board pattern
sProduction
number breakdown
HD - 090 03 S
1
2
3
4
1
Series Name: HD (Directional Couplers)
3
Degree of Coupling
2
Center Frequency
090 : 900MHz
150 : 1500MHz
190 : 1900MHz
200 : 2000MHz
215 : 2150MHz
03 : 3dB
10 : 10dB
16 : 16dB
21 : 21dB
23 : 23dB
4
Board Mounting Method
SH : SMT
SH : SMT High Power
qResist
processing should be performed around the electrode pads.
1
sSpecifications
Model No.
HD-09003S
HD-09010S
HD-09016S
HD-09023S
HD-15003S
HD-15010S
HD-15016S
HD-15021S
HD-19003S
HD-21503S
HD-20003SH
(MHz)
Frequency
Range
0800~1000
0840~1960
0840~1960
0840~1960
1400~1600
1400~1600
1400~1600
1400~1600
1850~1950
1900~2300
1900~2200
(dB)
Coupling
3
+0.4
0
10±1
16±1
23±1
3
+0.4
0
11±1
16±1
21±1
3
+0.4
0
3
+0.4
0
3
+0.4
0
Frequency
Sensitivity
±0.35
±0.4
±0.4
±0.4
±0.35
±0.4
±0.4
±0.4
±0.5
±0.5
±0.4
(dBMax)
Insertion
Loss
-----
0.4
0.4
0.4
-----
0.4
0.4
0.4
-----
-----
-----
(dB Min) (dB Min)
(Max)
(g)
Isolation Directivity V.S.W.R. Weight
20
-----
-----
-----
20
-----
-----
-----
20
20
20
-----
15
15
15
-----
15
10
10
-----
-----
-----
1.22
1.3
1.3
1.3
1.2
1.25
1.35
1.35
1.2
1.25
1.25
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.7
(W)
Power
10
20
20
20
10
20
20
20
20
20
50
q
The coupling loss component is not included in the insertion loss.
q
There is a 90
°
phase difference between the output and the coupling.
q
When ordering embossed tape packaged items, affix (06) to the end of the product number. One reel contains 1,000 pieces.
sExternal
dimensions
HD-09003S
HD-09010S
HD-09016S
HD-09023S
HD-15003S
HD-15010S
HD-15016S
HD-15021S
HD-19003S
HD-21503S
HD-20003SH
Degree of Coupling
3dB
10dB
16dB
21dB
input port
A
2.6
1.6
1.6
1.8
1.8
23dB
sUsage
precautions
1.Soldering
(1)Recommended temperature profile
1Up
to two cycles are permitted at the same conditions provided that the item is at room
temperature between the first and second cycle.
2The
temperature indicates the board surface temperature of the contact lead portion.
3Reflow
soldering should be performed at a peak temperature of 240ç or less at the surface of the
printed circuit board.
4The
temperature profile will change depending on the conditions which include board size, solder
used, and solder thickness.
(2)Recommended hand soldering conditions
Soldering iron temperature: 350ç,Soldering time: Within 5 s
(3)Recommended screen thickness
0.15 mm
2.Product Storage
1After
opening the package reseal promptly or store in a desiccator with a desiccant.
2Store
in a place that is not exposed to harmful gases which include sulfur or chlorine, etc.
3Use
within one year of delivery.
2
