LTR18EZPD33R0

Description
Fixed Resistor, Metal Glaze/thick Film, 0.5W, 33ohm, 200V, 0.5% +/-Tol, 100ppm/Cel, Surface Mount, 0612, CHIP
CategoryPassive components    The resistor
File Size171KB,4 Pages
ManufacturerROHM Semiconductor
Websitehttps://www.rohm.com/
Environmental Compliance
Download Datasheet Parametric View All

LTR18EZPD33R0 Overview

Fixed Resistor, Metal Glaze/thick Film, 0.5W, 33ohm, 200V, 0.5% +/-Tol, 100ppm/Cel, Surface Mount, 0612, CHIP

LTR18EZPD33R0 Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerROHM Semiconductor
package instructionSMT, 1206
Reach Compliance Codecompliant
ECCN codeEAR99
Other featuresSTANDARD: IEC60115-8, TS 16949
structureRECTANGULAR PACKAGE
JESD-609 codee3
Installation featuresSURFACE MOUNT
Number of terminals2
Maximum operating temperature155 °C
Minimum operating temperature-55 °C
Package height0.55 mm
Package length3.2 mm
Package formSMT
Package width1.6 mm
method of packingTR, Paper, 7 Inch
Rated power dissipation(P)0.75 W
Rated temperature70 °C
GuidelineAEC-Q200
resistance33 Ω
Resistor typeFIXED RESISTOR
size code1206
surface mountYES
Temperature Coefficient100 ppm/°C
Terminal surfaceTin (Sn) - with Nickel (Ni) barrier
Terminal shapeWRAPAROUND
Tolerance0.5%
Operating Voltage200 V
High Power Chip Resistors
<Wide Terminal type>
LTR18 (3216 size : 1 / 2W)
Features
1) mproved welding strength
The structure of longer electrodes provides the wider welding area than the chip resistors with normal electrodes, and this
enhanced the solder welding strength.
2) Increased surge-resistance
This is achieved by Rohm’s original trimming technology plus resistive element patterning.
3) High-power tolerance
Two times of the rated power is guaranteed than the normal-electrode resistors.
ROHM resistors are ISO-9001 & ISO/TS16949 certified.
Applications
Automotive, industrial and power supply.
Ratings
Design and specifications are subject to change without notice.
Carefully check the specification sheet before using or ordering it.
Item
Rated power
Conditions
Power must be derated according to the power derating curve in
Figure 1 when ambient temperature exceeds 70°C.
100
80
POWER LOAD (%)
Specifications
0.5W (1 / 2W)
at 70°C
60
40
20
0
−55
0
70
100
155
AMBIENT TEMPERATURE (
°
C)
Fig.1
Rated voltage
The voltage rating is calculated by the following equation.
If the value obtained exceeds the limiting element voltage,
the voltage rating is equal to the maximum operating voltage.
E: Rated voltage (V)
E= P×R
P: Rated power (W)
R: Nominal resistance (Ω)
Nominal resistance
Operating temperature
See Table 1.
Limiting element voltage
200V
D(±0.5%) F(±1%) J(±5%)
−55°
C to
+ 155°C
www.rohm.com
c
2009 ROHM Co., Ltd. All rights reserved.
1/3
2009.10- Rev.C
