GBPC3500-GBPC3510
Silicon Bridge Rectifiers
PRV : 50 - 1000 Volts
Io : 35 Amperes
BR-35
0.728(18.50)
0.688(17.40)
Features
High current capability
High surge current capability
High reliability
Low reverse current
Low forward voltage drop
Pb / RoHS Free
0.570(14.50)
0.530(13.40)
0.685(16.70) 1.130(28.70)
0.618(15.70) 1 120(28 40)
0.658(16.70)
0.618(15.70)
0.028(0.71)
0.024(0.61)
0.197(5.00)
0.193(4.90)
0.252(6.40)
0.248(6.30)
φ
0.094(2.40)
0.087(2.20)
1.141 (29.0)
1.063 (27.0)
Mechanical Data
Case : Metal Case
Epoxy : UL94V-O rate flame retardant
Terminals : plated .25" (6.35 mm). Faston
Polarity : Polarity symbols marked on case
Mounting position : Bolt down on heat-sink with
silicone thermal compound between bridge
and mounting surface for maximum heat
transfer efficiency.
Weight : 15.6 grams
Rating at 25
°
C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
0.325 (8.25)
0.309 (7.85)
Dimensions in inches and ( millimeters )
Maximum Ratings and Electrical Characteristics
RATING
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Current Tc = 55
°
C
Peak Forward Surge Current Single half sine wave
Superimposed on rated load (JEDEC Method)
Current Squared Time at t < 8.3 ms.
Maximum Forward Voltage per Diode at I
F
= 17.5 A
Maximum DC Reverse Current
at Rated DC Blocking Voltage
Typical Thermal Resistance (Note 1)
Typical Thermal Resistance at Junction to Ambient
Operating Junction Temperature Range
Storage Temperature Range
Ta = 25
°
C
Ta = 100
°
C
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
I
2
t
V
F
I
R
I
R(H)
R
θ
JC
R
θ
JA
T
J
T
STG
GBPC
3500
50
35
50
GBPC
3501
100
70
100
GBPC
3502
200
140
200
GBPC
3504
400
280
400
35
400
660
1.1
10
200
1.5
10
GBPC
3506
600
420
600
GBPC
3508
800
560
800
GBPC
3510
1000
700
1000
UNIT
V
V
V
A
A
A
2
S
V
μA
μA
°C/W
°C
°C
°C
- 40 to + 150
- 40 to + 150
Note :
(1) Thermal Resistance from junction to case with units mounted on a 7.5" x 3.5" x 4.6" (19cm.x 9cm.x 11.8cm.) Al.-Finned Plate
http://www.luguang.cn
mail:lge@luguang.cn
GBPC3500-GBPC3510
Silicon Bridge Rectifiers
RATING AND CHARACTERISTIC CURVES ( KBPC3500 - KBPC3510 )
FIG.1 - DERATING CURVE FOR OUTPUT
RECTIFIED CURRENT
42
FIG.2 - MAXIMUM NON-REPETITIVE PEAK
FORWARD SURGE CURRENT
600
8.3 ms SINGLE HALF SINE WAVE
JEDEC METHOD
AVERAGE FORWARD OUTPUT
CURRENT, AMPERES
PEAK FORWARD SURGE
CURRENT, AMPERES
35
500
T
J
= 50
°C
400
28
21
300
14
HEAT-SINK MOUNTING, Tc
7.5" x 3.5" x 4.6" THK.
(19cm x 9cm x 11.8cm)
Al.-Finned plate
200
7
100
0
0
25
50
75
100
125
150
175
0
1
2
4
6
10
20
40
60 100
CASE TEMPERATURE, (
°
C)
NUMBER OF CYCLES AT 60Hz
FIG.3 - TYPICAL FORWARD CHARACTERISTICS
PER DIODE
100
FIG.4 - TYPICAL REVERSE CHARACTERISTICS
PER DIODE
10
REVERSE CURRENT, MICROAMPERES
T
J
= 100
°C
FORWARD CURRENT, AMPERES
10
1.0
1.0
Pulse Width = 300
μs
1 % Duty Cycle
0.1
T
J
= 25
°C
T
J
= 25
°C
0.1
0.01
0
20
40
60
80
100
120
140
0.01
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
PERCENT OF RATED
REVERSE VOLTAGE, (%)
FORWARD VOLTAGE, VOLTS
http://www.luguang.cn
mail:lge@luguang.cn
