ATC200B203KT50XT Overview

RF Power Field Effect Transistor

Freescale Semiconductor
Technical Data
Document Number: MRF6V2150N
Rev. 4, 4/2010
RF Power Field-
-Effect Transistors
N--Channel Enhancement--Mode Lateral MOSFETs
Designed primarily for CW large--signal output and driver applications with
frequencies up to 450 MHz. Devices are unmatched and are suitable for use in
industrial, medical and scientific applications.
Typical CW Performance at 220 MHz: V
DD
= 50 Volts, I
DQ
= 450 mA,
P
out
= 150 Watts
Power Gain — 25 dB
Drain Efficiency — 68.3%
Capable of Handling 10:1 VSWR, @ 50 Vdc, 220 MHz, 150 Watts CW
Output Power
Features
Characterized with Series Equivalent Large--Signal Impedance Parameters
Qualified Up to a Maximum of 50 V
DD
Operation
Integrated ESD Protection
225°C Capable Plastic Package
RoHS Compliant
In Tape and Reel. R1 Suffix = 500 Units per 44 mm, 13 inch Reel.
MRF6V2150NR1
MRF6V2150NBR1
10-
-450 MHz, 150 W, 50 V
LATERAL N-
-CHANNEL
SINGLE-
-ENDED
BROADBAND
RF POWER MOSFETs
CASE 1486-
-03, STYLE 1
TO-
-270 WB-
-4
PLASTIC
MRF6V2150NR1
CASE 1484-
-04, STYLE 1
TO-
-272 WB-
-4
PLASTIC
MRF6V2150NBR1
PARTS ARE SINGLE-
-ENDED
Table 1. Maximum Ratings
Rating
Drain--Source Voltage
Gate--Source Voltage
Storage Temperature Range
Case Operating Temperature
Operating Junction Temperature
(1,2)
Symbol
V
DSS
V
GS
T
stg
T
C
T
J
Value
-- 0.5, +110
-- 0.5, + 12
-- 65 to +150
150
225
Unit
Vdc
Vdc
°C
°C
°C
(Top View)
Symbol
R
θJC
Value
(2,3)
0.24
Unit
°C/W
Note: Exposed backside of the package is
the source terminal for the transistor.
RF
in
/V
GS
RF
out
/V
DS
RF
in
/V
GS
RF
out
/V
DS
Table 2. Thermal Characteristics
Characteristic
Thermal Resistance, Junction to Case
Case Temperature 80°C, 150 W CW
Figure 1. Pin Connections
Table 3. ESD Protection Characteristics
Test Methodology
Human Body Model (per JESD22--A114)
Machine Model (per EIA/JESD22--A115)
Charge Device Model (per JESD22--C101)
Class
2 (Minimum)
A (Minimum)
IV (Minimum)
1. Continuous use at maximum temperature will affect MTTF.
2. MTTF calculator available at http://www.freescale.com/rf. Select Software & Tools/Development Tools/Calculators to access
MTTF calculators by product.
3. Refer to AN1955,
Thermal Measurement Methodology of RF Power Amplifiers.
Go to http://www.freescale.com/rf.
Select Documentation/Application Notes -- AN1955.
©
Freescale Semiconductor, Inc., 2007--2008, 2010. All rights reserved.
MRF6V2150NR1 MRF6V2150NBR1
1
RF Device Data
Freescale Semiconductor
