AP1301/2/4/5
Single Coil Fan Motor Full Wave Driver
Features
- Compatible to a Hall element
- Operating voltage (V
CC
) : 4V to 20V
- Lock shutdown and automatic restart
- Speed indication output (FG) named as AP1301/4
- Rotation detection output (RD) named as
AP1302/5
- Output current(AP1301/2) I
O
=500mA
(max)
- Output current(AP1304/5) I
O
=350mA
(max)
- Operating temperature (T
opr
) : -30ºC to +85ºC
- SOP-8L/ SOP-8L EP package
- Include Thermal Shutdown circuit
General Description
The AP1304/5 is single phase full wave drive
design, which is suited for small fans (such as CPU
cooling fans). The low switching noise and effective
motor drive are another advantage. All functions,
including lock shutdown, automatic restart, rotation
detection (RD), and speed indication output (FG)
have been incorporated into one chip. When the
motor is under lock condition, lock shutdown
function turns off the output current. When the lock
condition is removed, the IC automatically restarts
and allows DC fan to run. In addition, the RD
function is to detect the motor status and the FG is
to provide the rotation speed.
The AP1301/2 are heat sink version of AP1304/5.
From function wise, AP1301 is the same as
AP1304, and AP1302 is the same as AP1305.
Application
- CPU cooling fans
Pin Assignment
( Top view )
IN-
IN+
CT
OUT1
1
2
AP1301/2/4/5
3
4
SOP-8L
6
5
OUT2
GND
8
7
RD/FG
VCC
Pin Descriptions
Name
VCC
IN+
RD/FG
IN-
GND
CT
OUT2
OUT1
Description
Power input
Hall input
Rotation detection / Speed indication
Hall input
Ground
Timing capacitor
Driver output
Driver output
Ordering Information
AP130X X - X X X
Function
- RD output (1305)
without heat sink
- FG output (1304)
- RD output (1302)
with heat sink
- FG output (1301)
Wafer Body
Blank or
A~Z : if necessary
to specify
Package
Lead
Packing
Blank : Tube
A : Taping
Blank: Normal
S: SOP-8L
SP: SOP-8L EP L: Lead Free
This datasheet contains new product information. Anachip Corp. reserves the rights to modify the product specification without notice. No liability is assumed as a result of the use of
this product. No rights under any patent accompany the sale of the product.
Rev. 0.2 Apr. 16, 2004
1/5
AP1301/2/4/5
Single Coil Fan Motor Full Wave Driver
Absolute Maximum Ratings
Parameter
Input voltage
Output current
Maximum output withstand voltage
RD/FG maximum output withstand voltage
RD/FG maximum output current
Allowable power dissipation
Operating temperature
Storage temperature
*note1 : Reduced by 5.5mW for each increase in Ta of 1ºC over 25
ºC
(T
A
=25ºC)
Symbol
V
CC
AP1304/5
AP1301/2
Vout
Vr/Vf
Ir/If
AP1304/5
AP1301/2
T
OPR
T
STG
Rating
20
350
500
20
20
5
550*(note1)
1000
-30 to +85
-55 to +150
Unit
V
mA
V
V
mA
mW
ºC
ºC
I
OUT
P
D
Electrical Characteristics
( T =25ºC, V
A
CC
=5V, unless otherwise noted)
Parameter
Power supply voltage
Hall input voltage (DC+AC)
Supply current
Charge current
Discharge current
Charge/discharge ratio
Output Low Level Voltage
Output High Level Voltage
Hall input sensitivity
RD/FG pin output low
RD/FG output pin leakage
current
Symbol
Vcc
V
BH
I
CC
I
CHG
I
DHG
R
CD
Vol
Voh
V
HN
Conditions
Min.
4
0.2
--
1.9
0.32
5.0
3.9
Rating
Typ.
Max.
--
--
6.5
2.8
0.46
6.0
0.2
4.1
7
15
0.3
30
20
V
CC
-1.5
10
3.7
0.60
7.0
0.3
Unit
V
V
mA
uA
uA
--
V
V
mV
V
uA
Includes the amplitude of signal
The output is off
V
CT
= 1.5V
V
CT
= 1.5V
I
GHG
/I
DCHG
Io=200mA
Io=200mA
Zero peak value (including
offset and hysteresis)
V
RDL,
Vfgl I
RD ,
Ifg = 5mA
Irdl,Ifgl
Vrd,Vfg=15V
--
0.1
Truth Table
IN-
H
L
-
IN+
L
H
-
CT
L
L
H
OUT1
H
L
off
OUT2
L
H
off
RD
L
L
off
FG
L
H
-
Mode
Rotating
Rotating
Lockup protection activated
Latch-type RD output is low during rotation and high during stop
Anachip Corp.
www.anachip.com.tw
3/5
Rev 0.2 Apr.16, 2004
