NSD914X datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> Small signal switching diode> NSD914X

NSD914X: DescriptionHigh Speed Switching Diode; CategoryDiscrete semiconductor Small signal switching diode; File Size328KB，2 Pages; ManufacturerLGE; Websitehttp://www.luguang.cn/web_en/index.html

Download Datasheet Parametric View All

NSD914X Overview

High Speed Switching Diode

NSD914X Parametric

Parameter Name	Attribute value
Case Style	SOD-523
IF（mA）	200
Maximum recurrent peak reverse voltage	100
TRR（nS)	4.0
Maximum instantaneous forward voltage	1.0
@IF（uA）	10
Maximum reverse curre	5.0
@VR	75
class	Diodes

Preview

Download Datasheet

View All

NSD914X

High Speed Switching Diode

SOD-523

Features

Lead finish:100% matte Sn(Tin).

High speed switching application.

Extremely small SOD-523 package.

Qualified maximum reflow temperature:260℃

Applications

High-speed switching.

Dimensions in inches and (millimeters)

Ordering Information

Type No.

NSD914X

Marking

Package Code

SOD-523

MAXIMUM RATING

@ Ta=25℃ unless otherwise specified

Parameter

Continuous reverse voltage

Continuous forward current

Non-repetitive peak forward surge current

Total power dissipation

Thermal resistance junction-to-ambient

Junction temperature

Storage temperature

Symbol

FSM

tot

θJA

stg

Limits

100

200

500

200

635

150

-65-150

Unit

℃/W

℃

ELECTRICAL CHARACTERISTICS

@ Ta=25℃ unless otherwise specified

Parameter

Reverse breakdown voltage

Forward voltage

Reverse current

Diode capacitance

Reverse recovery time

Symbol

(BR)

Min.

100

1.0

5.0

4.0

Max.

Unit

μA

Conditions

=100μA

=10mA

=20V

=75V

=0,f=1MHz

=10mA,I

=10mA

http://www.luguang.cn

mail:lge@luguang.cn
