HGL341A datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> High efficiency rectifier diode> HGL341A

HGL341A: DescriptionSURFACE MOUNT GLASS; CategoryDiscrete semiconductor High efficiency rectifier diode; File Size592KB，2 Pages; ManufacturerLGE; Websitehttp://www.luguang.cn/web_en/index.html

Download Datasheet Parametric Compare View All

HGL341A Overview

SURFACE MOUNT GLASS

HGL341A Parametric

Parameter Name	Attribute value
Case Style	DO-213AA
Maximum average forward rectified curre	1.0
Maximum recurrent peak reverse voltage	50
Peak forward surge curre	10
Maximum instantaneous forward voltage	1.1
Maximum reverse curre	5.0
TRR(nS)	50
class	Diodes

Preview

Download Datasheet

View All

HGL341A thru HGL341M

SURFACE

SURFACE MOUNT GLASS

FEATURES

Ldeal for surface mounted applications

Low leakage current

Glass passivated chips

High temperature soldering guaranteed

250

C/10 seconds/.375 , (9.5mm) lead lengths

DO-213AA / MINI MELF

SOLDERABLE ENDS

D1= 0.066(1.676)

0.060(1.524)

CATHODE BAND

MECHANICAL DATA

Molded plastic use UL94V-0 recoqnized

flame retardant epoxy

Terminals Plated terminals, solderable per

MIL-STD-202, Method208

Polarity Color band on body denotes cathode

Mounting position Any

Weight 0.036gram

Case

0.022(0.559)

0.016(0.406)

0.145(3.683)

0.131(3.327)

D2=D1 +0

-0.008(0.20)

Dimension in inches (millimeters )

MAXIMUM RATIXGS AND ELECTRICAL CHARACTERISTICS

Ratings at 25

C ambient temp. unless otherwise specified

Single phase, half sine wave, 60Hz, resistive or inductive load

For capacitive load, derate current by 20%

SYMBOL

Maximum Current Peak Reverse Voltage

Maximum RMS Voltage

Maximum DC Blocking Voltage

Maximum Average Forward Rectified Current T

=55

Peak Forward Surge Current Single Sine-Wave on Rated

Load (JEDEC Method)

Maximum Instantaneous Forward Voltage Drop at 1.0A DC

Maximum DC Reverse Current T

=25

at Rated DC Blocking Voltage T

=125

Maximum Reverse Recovery Time, Test Conditions I

=0.5A,

=1.0A , I

=0.25A

Typical Junction Capacitance

Operating Junction and Storage Temperature Range

RRM

RMS

(AV)

FSM

1.1

HGL

341A

HGL

341B

HGL

341D

HGL

341G

HGL

341J

HGL

341K

HGL

341M

UNITS

Volts

Amps

100

200

140

200

400

280

400

1.0

1.3

5.0

100

600

420

600

800

560

800

1000

700

1000

1.75

Volts

STG

-55 to +150

http://www.luguang.cn Email:lge@luguang.cn

HGL341A Related Products

	HGL341A	HGL341B	HGL341D	HGL341G	HGL341J	HGL341K	HGL341M
Description	SURFACE MOUNT GLASS	SURFACE MOUNT GLASS	SURFACE MOUNT GLASS	SURFACE MOUNT GLASS	SURFACE MOUNT GLASS	SURFACE MOUNT GLASS	SURFACE MOUNT GLASS
Case Style	DO-213AA	DO-213AA	DO-213AA	DO-213AA	DO-213AA	DO-213AA	DO-213AA
Maximum average forward rectified curre	1.0	1.0	1.0	1.0	1.0	1.0	1.0
Maximum recurrent peak reverse voltage	50	100	200	400	600	800	1000
Peak forward surge curre	10	10	10	10	10	10	10
Maximum instantaneous forward voltage	1.1	1.1	1.1	1.35	1.75	1.75	1.75
Maximum reverse curre	5.0	5.0	5.0	5.0	5.0	5.0	5.0
TRR(nS)	50	50	50	50	75	75	75
class	Diodes	Diodes	Diodes	Diodes	Diodes	Diodes	Diodes
