F996-ND: DescriptionELECTRIC FUSE, 30A, 32VDC, 1000A (IR), INLINE/HOLDER; CategoryCircuit protection; File Size172KB，2 Pages; ManufacturerLittelfuse; Websitehttp://www.littelfuse.com

Download Datasheet View All

F996-ND Overview

ELECTRIC FUSE, 30A, 32VDC, 1000A (IR), INLINE/HOLDER

Preview

Download Datasheet

View All

Blade Fuses

ATO

®

Blade Fuse Rated 32V

Specifications

Voltage Rating:

Interrupting Ratings:

Operating Temperature Range:

32 VDC

1000A @ 32 VDC

-40˚C to +105˚C

Blade Fuses

Developed by Littelfuse for the automotive industry, the ATO

fuse has become the original equipment circuit protection

standard for foreign and domestic automobiles and trucks.

Readily identifiable and easily replaced, this fuse can be

specified for a variety of low voltage electronic applications.

Die ATO-Sicherung wurde von Littelfuse speziell für

die Fahrzeugindustrie entwickelt und hat sich als OEM-

Schaltungsschutz-Standard für in- und ausländische Personen-

und Lastkraftwagen etabliert. ATO-Sicherungen lassen sich

leicht identifizieren und austauschen und können für zahlreiche

Anwendungen im Niederspannungsbereich spezifiziert werden.

Time-Current Characteristics / Schmelzzeit-Grenzwerte

% of Rating

% des Nennstromes

110

135

200

350

600

Opening Time Min / Max (s)

Schmelzcharakteristik Min / Max (s)

100 hrs / –

500 ms / 600 s

750 ms / 600 s

100 ms / 5.0 s

150 ms / 5.0 s

20 ms / 500 ms

80 ms / 500 ms

– / 100 ms

– / 150 ms

Part Number

Artikel-Nr.

0257001_

0257002_

0257003_

0257004_

0257005_

025707.5_

0257010_

0257015_

0257020_

0257025_

0257030_

0257035_

0257040_

Current Rating

Nennstrom

1A

2A

3A

4A

5A

7.5 A

10 A

15 A

20 A

25 A

30 A

35 A

40 A

Housing Color

Kennfarbe

Typ. Voltage Drop

Typ. Spannungsfall

176 mV

141 mV

137 mV

136 mV

128 mV

116 mV

109 mV

102 mV

98 mV

92 mV

84 mV

87 mV

96 mV

Cold Resistance

Kaltwiderstand

123 mΩ

53.5 mΩ

31.1 mΩ

22.8 mΩ

17.85 mΩ

10.91 mΩ

7.70 mΩ

4.80 mΩ

3.38 mΩ

2.52 mΩ

1.97 mΩ

1.61 mΩ

1.44 mΩ

I

t

0.4 A²s

1.4 A²s

7.4 A²s

14 A²s

26 A²s

60 A²s

115 A²s

340 A²s

520 A²s

1080 A²s

1510 A²s

2280 A²s

3310 A²s

Last figure of part number = packaging code, see Section “Packaging Index,” pg. 157.

Corresponding holder see Section “Fuse Holders.”

www.littelfuse.com

•

Automotive Circuit Protection Products
