536526-1 Product Details
Live Product Chat
Product View
2mm Centerline Futurebus+ Connectors
Not EU R oHS or ELV C om plia nt
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
536526-1
T E I nternal N umber: 5 3 6 5 2 6 - 1
Product Highlights:
l
Module Type = Signal
l
24 Signal Positions
l
Fixed-Board (Header)
l
Mating Post Length = 6.50 mm
l
PC B Mount Angle = Vertical
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
PIN ASSEMBLY, SIGNAL MODULE, Z-PAC K 2mm FB, 2mm
(PDF, English)
Catalog Pages/Data Sheets:
l
Z-PAC K 2MM FB FUTUREBUS C ONNEC TORS
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
Z-PAC K 2mm FB (Futurebus+) Receptacle and Pin Header...
(PDF, English)
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Fixed-Board (Header)
l
PC B Mount Angle
= Vertical
l
Post Type
= Press-Fit
l
C omment = Sequencing of the mating posts and lead lengths is
available. Worksheets for this procedure may be found under Z-
PAC K 2mm FB General Information.; For feed-through shroud
availability, contact AMP, Inc.
Mechanical Attachment:
l
Module Type
= Signal
l
Mating Post Length (mm [in])
= 6.50 [0.256]
l
Press-Fit Post Style = C ompliant Pin
l
Pin Header Width (mm [in]) = 16.00 [0.622]
Electrical Characteristics:
l
Voltage Rating (VAC ) = 30
Termination Related Features:
l
Termination Post Length (mm [in])
= 13.60 [0.535]
Body Related Features:
l
Number of Signal Positions
= 24
l
Sequencing
= No
l
Number of Rows
= 4
l
Post Plating
= Tin Lead over Nickel
l
C enterline, Matrix (mm [in]) = 2.00 x 2.00 [.079 x .079]
Contact Related Features:
l
C ontact Base Material = Phosphor Bronze
l
C ontact Mating Area Plating Material = Gold Flash over Palladium
Nickel
Housing Related Features:
l
Housing Material = Liquid C rystal Polymer (LC P)
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Not relevant for lead free process
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
