52-255-008: DescriptionBarrier Strip Terminal Block, 60A, 2 Row(s), 1 Deck(s); CategoryThe connector; File Size108KB，1 Pages; ManufacturerAPI Technologies; Websitehttp://www.apitech.com/about-api

Download Datasheet Parametric Compare View All

52-255-008 Overview

Barrier Strip Terminal Block, 60A, 2 Row(s), 1 Deck(s)

52-255-008 Parametric

Parameter Name	Attribute value
Maker	API Technologies
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	HIGH CURRENT, POLYAMIDE, 94V-0
Fastening method	SCREW
Installation type	BOARD
Number of layers	1
Rows	2
Number of channels	16
Rated current	60 A
Rated voltage	75 V
Terminal and terminal strip types	BARRIER STRIP TERMINAL BLOCK
Wire gauge	12 AWG

Preview

Download Datasheet

View All

High Current

Filtered Terminal Blocks

Features

s

Specifications

ELECTRICAL

Voltage rating:

Capacitance:

75 VDC per terminal

.015µF* +80% / -20% per cap

.030µF +80% / -20% per pair

Applications

Telecommunications switching networks

s

Cellular base stations

s

Power supplies

s

UPS

s

Instrumentation

s

High reliability radar and transmission systems

s

Industrial controls

s

Power distribution

s

Dielectric

withstanding voltage:

1000 VRMS or

1500VDC for 1 minute

Current rating:

up to 60 Amps per terminal

Typical Insertion Loss — dB:

In 50 Ohm Circuit

1

5

10

50

MHz....... 8

MHz....... 24

MHz....... 32

MHz....... 38

70

100

160

200

MHz......... 36

MHz......... 33

MHz......... 25

A

.38

(9.65)

B

ø .200 (4x)

.75

(19.05)

.75

(19.05)

.75

(19.05)

TYP.

1.68

(42.67)

1.50

(38.1)

.50

(12.7)

.78

(19.81)

.38

(9.65)

.67

(17.01)

TYP. MIN.

C

.75

(19.05)

TYP.

.025 x 45° CHAMFER (13x)

.06

(1.52)

TYP.

FULL RADIUS TYP.

.38

(9.65)

.20

(5.08)

.97

(24.63)

REF.

.55

(13.97)

.35

(8.89)

REF.

.55

(13.97)

MAX.

.09

(2.28)

TYP.

M5x.8 THREAD

MECHANICAL

Center spacing:

Wire size:

Screw material:

Recommended PCB

hole diameter:

Molded material:

Tightening torque:

Terminal:

US .200: (5.08 mm)

AWG #12-26

steel, zinc chromate plate

.05" (1.30 mm) contact hole

UL rated 94VO polyamide

2.5 in.-lbs. max.

Brass, tin-plated

* For filter elements with additional capacitance values,

consult factory.

Part Number

52-255-002

52-255-003

52-255-004

52-255-005

52-255-006

52-255-007

52-255-008

52-255-009

52-255-010

52-255-011

52-255-012

52-255-013

Number of

Terminals

2x2

2x3

2x4

2x5

2x6

2x7

2x8

2x9

2x10

2x11

2x12

2x13

A

in.

3.01

3.76

4.51

5.26

6.01

6.75

7.51

8.26

9.01

9.76

10.51

11.26

(mm)

76.45

95.50

114.55

133.60

152.65

171.45

190.75

209.80

228.85

247.90

266.95

286.00

in.

2.25

3.00

3.75

4.50

5.25

6.00

6.75

7.50

8.25

9.00

9.75

10.50

B

(mm)

57.15

76.20

95.25

114.30

133.35

152.40

171.45

190.50

209.55

228.60

247.65

266.70

in.

.75

1.50

2.25

3.00

3.75

4.50

5.25

6.00

6.75

7.50

8.25

9.00

C

(mm)

19.05

38.10

57.15

76.20

95.25

114.30

133.35

152.40

171.45

190.50

209.55

228.60

Dimensions in inches

(mm)

SPECTRUM CONTROL INC.

• 8031 Avonia Rd. • Fairview, PA 16415 • Phone: 814-835-1650 • Fax: 814-835-1651 • Web site: www.spectrumcontrol.com

SPECTRUM CONTROL GmbH

• Hansastrasse 6 • 91126 Schwabach, Germany • Phone: (49)-9122-795-0 • Fax: (49)-9122-795-58

25

Filtered Terminal Blocks

s

Ideal for high current applications

Design flexibility

Available in 2 x 2 thru 2 x 13 positions

Designed to meet agency approval
