Pin Strip |
Spacing 5.0 mm
STL950/..F-5.0-H-P2.6-BK-HT
Technical Data
Wire sizes
Solid min
Solid max
Stranded (flexible) min
Stranded (flexible) max
Stranded with Ferrule min
Stranded with Ferrule max
-
-
-
-
-
-
Order Data (Spacing 5.0 mm)
Insulating Material
Material
Flammability Class
PPA
UL 94 V-0
2
3
4
20.00
25.00
30.00
35.00
40.00
STL950/2F-5.0-H-P2.6-BK-HT
STL950/3F-5.0-H-P2.6-BK-HT
STL950/4F-5.0-H-P2.6-BK-HT
STL950/5F-5.0-H-P2.6-BK-HT
STL950/6F-5.0-H-P2.6-BK-HT
Poles
Width (mm)
Article Designation
Article
Number
50950026347R
50950036347R
50950046347R
50950056347R
50950066347R
PU
330
330
330
330
330
Temperatures
Operating Temperature
(without mech. load)
Store Temperature
-40 °C - 105 °C
-40 °C - 105 °C
5
6
Dimensions
PCB Hole Diameter
1.4 mm
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
260 °C
3-4 s
Accessoires
Figure
Designation
Article Number
Coding Star CS2-5.0/5.08-LIGHT Order Data: 50000000028
GREY-HT
Materials
Thread Insert, Flange
Contact Pin
Brass
Copper
Alloy
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
217 - 245 °C
60 s
Tape on Reel
Poles
2
3
4
Reel (RD/")
13
13
13
13
13
Width (R/mm) Pitch (RP/mm)
56
56
56
56
56
16
16
16
16
16
Pieces (PCS)
330
330
330
330
330
Colours
BLACK, RAL 9011
Colours according to RAL, there may be variations on colour due to production conditions.
5
6
Counterparts (Spacing 5.0 mm)
Terminal Block
AK950
AK1200
AK4951
In combination of connectors with different admission data, the lower value is valid.
Ratings
UseGroup
Rated Voltage
Rated Current
Overvoltage Category
Test Voltage
Pollution Degree
B
300 V
15 A
C
150 V
15 A
D
300 V
10 A
250 V
12 A
III
1.60 kV
1.30 kV
1.60 kV
4.0 kV
3
PTR HARTMANN GmbH
• Gewerbehof 38 • 59368 Werne / Germany
Telefon: +49 (0)2389/7988-0 •
E-Mail: info@ptr-hartmann.com
www.ptr.eu
