532920-9 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 532920-9

532920-9: DescriptionFEMALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER, RECEPTACLE; CategoryThe connector The connector; File Size279KB，2 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

532920-9 Overview

FEMALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER, RECEPTACLE

532920-9 Parametric

Parameter Name	Attribute value
Objectid	2110379202
Reach Compliance Code	unknown
YTEOL	0
Body/casing type	RECEPTACLE
Connector type	BOARD CONNECTOR
Contact point gender	FEMALE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Mixed contacts	NO
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of connectors	ONE
Number of rows loaded	4
Options	GENERAL PURPOSE
Terminal pitch	2.54 mm
Termination type	SOLDER

Preview

Download Datasheet

View All

532920-9 Related Products

	532920-9	532920-8	532920-5
Description	FEMALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER, RECEPTACLE	HEADER CONNECTOR,PCB MNT,PLUG,488 CONTACTS,SKT,0.1 PITCH,PC TAIL TERMINAL,#2-56,NATURAL	HEADER CONNECTOR,PCB MNT,PLUG,416 CONTACTS,SKT,0.1 PITCH,PC TAIL TERMINAL,#2-56,NATURAL
Objectid	2110379202	301475430	301475428
Reach Compliance Code	unknown	unknown	compliant
Body/casing type	RECEPTACLE	PLUG	PLUG
Connector type	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR
Contact point gender	FEMALE	FEMALE	FEMALE
Filter function	NO	NO	NO
Mixed contacts	NO	NO	NO
Installation method	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE
Installation type	BOARD	BOARD	BOARD
Number of connectors	ONE	ONE	ONE
Number of rows loaded	4	4	4
Terminal pitch	2.54 mm	2.54 mm	2.54 mm
Termination type	SOLDER	SOLDER	SOLDER
ECCN code	-	EAR99	EAR99
Other features	-	MOUNT, EARS OPTIONAL	MOUNT, EARS OPTIONAL
Board mount options	-	#2-56 THD HOLE	#2-56 THD HOLE
body width	-	0.46 inch	0.46 inch
subject depth	-	0.824 inch	0.824 inch
body length	-	13.25 inch	11.45 inch
Contact to complete cooperation	-	AU	AU
Contact completed and terminated	-	NICKEL	NICKEL
Contact material	-	BERYLLIUM COPPER	BERYLLIUM COPPER
contact mode	-	RECTANGULAR	RECTANGULAR
Contact style	-	SQ PIN-SKT	SQ PIN-SKT
Durability	-	250 Cycles	250 Cycles
Insulator color	-	NATURAL	NATURAL
insulator material	-	GLASS FILLED POLYPHENYLENE SULFIDE	GLASS FILLED POLYPHENYLENE SULFIDE
Plug contact pitch	-	0.1 inch	0.1 inch
Match contact row spacing	-	0.1 inch	0.1 inch
Installation option 1	-	#2-56	#2-56
Installation option 2	-	THREADED	THREADED
PCB row number	-	4	4
Maximum operating temperature	-	125 °C	125 °C
Minimum operating temperature	-	-65 °C	-65 °C
PCB contact pattern	-	RECTANGULAR	RECTANGULAR
PCB contact row spacing	-	2.54 mm	2.54 mm
Plating thickness	-	30u inch	30u inch
polarization key	-	POLARIZED KEY	POLARIZED KEY
Guideline	-	UL, CSA	UL, CSA
Terminal length	-	0.18 inch	0.18 inch
Total number of contacts	-	488	416
