Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
2R3S THRU 20R3S
Part Number/Ordering Information
1/
__
R3S
__
└
│
Screening
3/
│
│
│
│
└
Family/Voltage
2 = 20V
3 = 30V
4 = 40V
5 = 50V
7 = 70V
10 = 100V
12 = 125V
15 = 150V
20 = 200V
Designer’s Data Sheet
__
= Not Screened
TX = TX Level
TXV = TXV Level
S = S Level
•
•
•
•
•
•
•
8 AMPS
20 – 200 VOLTS
35 nsec
HYPER FAST RECTIFIER
Features
:
Hyper Fast Recovery: 35nsec Maximum
Low Forward Voltage Drop
Low Reverse Leakage Current
Single Chip Construction
Hermetically Sealed Package
Metalurgically Bonded Construction
TX, TXV, and S-Level Screening Available
2/
Maximum Ratings
2/
2R3S
3R3S
4R3S
5R3S
7R3S
10R3S
12R3S
15R3S
20R3S
Symbol
Value
20
30
40
50
70
100
125
150
200
8
200
-65 to +175
1.5
DO-4:
Units
Peak Repetitive Reverse Voltage
V
RRM
V
RWM
V
R
Volts
Average Rectified Forward Current
(Resistive Load, 60 Hz Sine Wave, T
A
= 25 °C)
Io
I
FSM
T
OP
&
T
STG
R
θJC
Amps
Amps
ºC
ºC/W
Peak Surge Current
(8.3 ms Pulse, Half Sine Wave, T
A
= 25 °C)
Operating & Storage Temperature
Maximum Total Thermal Resistance
Junction to Case
Notes:
1/ For ordering information, Price, Operating Curves, and Availability- Contact Factory.
2/ Unless Otherwise Specified, All Maximum Ratings/Electrical Characteristics @25°C.
3/ Screened to MIL-PRF-19500.
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RC0029D
DOC
Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, CA 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
2R3S THRU 20R3S
Electrical Characteristics
Instantaneous Forward Voltage Drop
(I
F
=8A, T
A
=25 ºC, 300μsec
pulse)
Reverse Leakage Current
(Rated V
R
, T
A
=25 ºC, 300μsec
pulse minimum)
Reverse Leakage Current
(Rated V
R
, T
A
=100 ºC, 300μsec
pulse minimum)
Reverse Recovery Time
(T
A
=25 ºC, I
F
= 0.5A, I
R
= 1.0A, I
RR
= 0.25A)
Typical Junction Capacitance
(V
R
= 10V
DC
, T
A
= 25ºC, f = 1MHz)
Notes:
1/ For ordering information, Price, Operating Curves, and Availability- Contact Factory.
2/ Screened to MIL-PRF-19500.
3/ Unless Otherwise Specified, All Maximum Ratings/Electrical Characteristics @25°C.
Symbol
V
F
Max
0.90
Units
V
DC
I
R1
I
R2
t
RR
C
J
100
2.0
35
300
μA
mA
nsec
pF
Case Outline: DO-4
Stud: Cathode
Lead: Anode
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RC0029D
DOC
