CUSTOMER DRAWING
Part Name
B-151-05
B-151-07
B-151-11
B-151-13
B-151-17
Component Dimensions
A
B
L
min
min
max
4.3
4.8
29.3
(.169)
(.189)
(1.154)
6.4
7.3
32.5
(.250)
(.290)
(1.280)
10.0
11.5
35.5
(.395)
(.450)
(1.395)
13.0
15.1
45.5
(.510)
(.595)
(1.790)
16.5
19.0
55.0
(.650)
(.750)
(2.165)
D
max
4.8
(.189)
7.3
(.290)
11.5
(.450)
15.1
(.595)
18.0
(.710)
E
min
2.0
(.079)
3.3
(.130)
4.5
(.175)
7.0
(.275)
9.0
(.355)
Cable Dimensions
F
G
min
max
1.5
4.3
(.059)
(.169)
2.8
6.4
(.110)
(.250)
4.0
10.0
(.155)
(.395)
6.5
13.0
(.255)
(.510)
8.0
16.0
(.315)
(.630)
J0.5
(J.020)
9.0
(.354)
11.0
(.435)
13.0
(.510)
17.0
(.670)
23.0
(.905)
MATERIAL
1. INSULATION SLEEVE: Radiation cross-linked modified polyolefin. Transparent clear.
2. SOLDER PREFORM WITH FLUX:
SOLDER: TYPE Cd18 per ANSI J-STD-006.
FLUX:
TYPE ROM1 per ANSI J-STD-004.
3. & 4. MELTABLE SEALING RINGS: Thermally stabilized thermoplastic.
5. GROUND LEAD: RAYCHEM 100G0111-1.00-9, stranded tin plated copper. Color: white.
APPLICATION
1. These controlled soldering devices are designed for termination of a bare or tin plated copper shield on a cable having an insulation
rated for at least 85C.
2. Temperature range: -55C to +125C.
3. For installation procedure and application equipment consult RPIP-688-01.
For best results, prepare the cable as shown:
TE Connectivity
300 Constitution Dr
Menlo Park, CA
94025, U.S.A.
TITLE:
SOLDERSLEEVE LOW-FIRE-HAZARD
WITH PRE-INSTALLED LEAD
.
DOCUMENT NO.:
Unless otherwise specified dimensions are in millimeters.
[Inches dimensions are shown in brackets]
TOLERANCES:
0.00 N/A
0.0 N/A
0 N/A
REVISED BY:
ANGLES: N/A
ROUGHNESS
IN MICRON
CAGE CODE:
Raychem
Devices
B-151-XX
REV:
DATE:
TE Connectivity reserves the right to amend
this drawing at any time. Users should
evaluate the suitability of the product for
their application.
ECO NUMBER:
E1
SCALE:
SIZE:
15-Apr-11
SHEET:
HMR
06090
ECO-11-005139
© 1998,2011 Tyco Electronics Corporation, a TE Connectivity Ltd. Company.
If this document is printed it becomes uncontrolled. Check for the latest revision.
NTS
A
1 of 1
Print Date:4/15/2011
