Freescale Semiconductor
Data Sheet: Advance Information
Document Number: K53P144M100SF2V2
Rev. 1, 6/2012
Supports the following:
MK53DN512CLQ10,
MK53DN512CMD10,
MK53DX256CLQ10,
MK53DX256CMD10
Features
• Operating Characteristics
– Voltage range: 1.71 to 3.6 V
– Flash write voltage range: 1.71 to 3.6 V
– Temperature range (ambient): -40 to 85°C
• Performance
– Up to 100 MHz ARM Cortex-M4 core with DSP
instructions delivering 1.25 Dhrystone MIPS per
MHz
• Memories and memory interfaces
– Up to 512 KB program flash memory on non-
FlexMemory devices
– Up to 256 KB program flash memory on
FlexMemory devices
– Up to 256 KB FlexNVM on FlexMemory devices
– 4 KB FlexRAM on FlexMemory devices
– Up to 128 KB RAM
– Serial programming interface (EzPort)
– FlexBus external bus interface
• Clocks
– 3 to 32 MHz crystal oscillator
– 32 kHz crystal oscillator
– Multi-purpose clock generator
• System peripherals
– Multiple low-power modes to provide power
optimization based on application requirements
– Memory protection unit with multi-master
protection
– 16-channel DMA controller, supporting up to 63
request sources
– External watchdog monitor
– Software watchdog
– Low-leakage wakeup unit
• Security and integrity modules
– Hardware CRC module to support fast cyclic
redundancy checks
– Hardware random-number generator
– Hardware encryption supporting DES, 3DES, AES,
MD5, SHA-1, and SHA-256 algorithms
– 128-bit unique identification (ID) number per chip
• Human-machine interface
– Segment LCD controller supporting up to 40
frontplanes and 8 backplanes, or 44 frontplanes and
4 backplanes, depending on the package size
– Low-power hardware touch sensor interface (TSI)
– General-purpose input/output
• Analog modules
– Two 16-bit SAR ADCs
– Programmable gain amplifier (PGA) (up to x64)
integrated into each ADC
– Two 12-bit DACs
– Two operational amplifiers
– Two transimpedance amplifiers
– Three analog comparators (CMP) containing a 6-bit
DAC and programmable reference input
– Voltage reference
• Timers
– Programmable delay block
– Eight-channel motor control/general purpose/PWM
timer
– Two 2-channel quadrature decoder/general purpose
timers
– IEEE 1588 timers
– Periodic interrupt timers
– 16-bit low-power timer
– Carrier modulator transmitter
– Real-time clock
K53 Sub-Family
K53P144M100SF2V2
This document contains information on a new product. Specifications and
information herein are subject to change without notice.
© 2012 Freescale Semiconductor, Inc.
Preliminary
General Business Information
• Communication interfaces
– Ethernet controller with MII and RMII interface to external PHY and hardware IEEE 1588 capability
– USB full-/low-speed On-the-Go controller with on-chip transceiver
– Three SPI modules
– Two I2C modules
– Six UART modules
– Secure Digital host controller (SDHC)
– I2S module
K53 Sub-Family Data Sheet, Rev. 1, 6/2012.
2
Preliminary
General Business Information
Freescale Semiconductor, Inc.
Table of Contents
1 Ordering parts...........................................................................5
1.1 Determining valid orderable parts......................................5
2 Part identification......................................................................5
2.1 Description.........................................................................5
2.2 Format...............................................................................5
2.3 Fields.................................................................................5
2.4 Example............................................................................6
3 Terminology and guidelines......................................................6
3.1 Definition: Operating requirement......................................6
3.2 Definition: Operating behavior...........................................7
3.3 Definition: Attribute............................................................7
3.4 Definition: Rating...............................................................8
3.5 Result of exceeding a rating..............................................8
3.6 Relationship between ratings and operating
requirements......................................................................8
3.7 Guidelines for ratings and operating requirements............9
3.8 Definition: Typical value.....................................................9
3.9 Typical value conditions....................................................10
4 Ratings......................................................................................11
4.1 Thermal handling ratings...................................................11
4.2 Moisture handling ratings..................................................11
4.3 ESD handling ratings.........................................................11
4.4 Voltage and current operating ratings...............................11
5 General.....................................................................................12
5.1 AC electrical characteristics..............................................12
5.2 Nonswitching electrical specifications...............................12
5.2.1
5.2.2
5.2.3
5.2.4
5.2.5
5.2.6
5.2.7
5.2.8
Voltage and current operating requirements......13
LVD and POR operating requirements...............14
Voltage and current operating behaviors............14
Power mode transition operating behaviors.......15
Power consumption operating behaviors............16
EMC radiated emissions operating behaviors....19
Designing with radiated emissions in mind.........20
Capacitance attributes........................................20
6.8.6
6.6.7
6.6.6
5.4.2
Thermal attributes...............................................22
6 Peripheral operating requirements and behaviors....................23
6.1 Core modules....................................................................23
6.1.1
6.1.2
Debug trace timing specifications.......................23
JTAG electricals..................................................24
6.2 System modules................................................................27
6.3 Clock modules...................................................................27
6.3.1
6.3.2
6.3.3
MCG specifications.............................................27
Oscillator electrical specifications.......................29
32 kHz Oscillator Electrical Characteristics........32
6.4 Memories and memory interfaces.....................................32
6.4.1
6.4.2
6.4.3
Flash electrical specifications.............................32
EzPort Switching Specifications.........................37
Flexbus Switching Specifications........................38
6.5 Security and integrity modules..........................................41
6.6 Analog...............................................................................41
6.6.1
6.6.2
6.6.3
6.6.4
6.6.5
ADC electrical specifications..............................41
CMP and 6-bit DAC electrical specifications......49
12-bit DAC electrical characteristics...................52
Op-amp electrical specifications.........................55
Transimpedance amplifier electrical
specifications — full range..................................56
Transimpedance amplifier electrical
specifications — limited range............................57
Voltage reference electrical specifications..........58
6.7 Timers................................................................................59
6.8 Communication interfaces.................................................59
6.8.1
6.8.2
6.8.3
6.8.4
6.8.5
Ethernet switching specifications........................59
USB electrical specifications...............................61
USB DCD electrical specifications......................61
USB VREG electrical specifications...................62
DSPI switching specifications (limited voltage
range).................................................................62
DSPI switching specifications (full voltage
range).................................................................64
6.8.7
6.8.8
6.8.9
6.8.10
I2C switching specifications................................66
UART switching specifications............................66
SDHC specifications...........................................66
I2S/SAI Switching Specifications........................67
5.3 Switching specifications.....................................................20
5.3.1
5.3.2
Device clock specifications.................................20
General switching specifications.........................21
5.4 Thermal specifications.......................................................22
5.4.1
Thermal operating requirements.........................22
K53 Sub-Family Data Sheet, Rev. 1, 6/2012.
Freescale Semiconductor, Inc.
Preliminary
General Business Information
3
6.9 Human-machine interfaces (HMI)......................................73
6.9.1
6.9.2
TSI electrical specifications................................73
LCD electrical characteristics.............................74
7.1 Obtaining package dimensions.........................................76
8 Pinout........................................................................................76
8.1 K53 Signal Multiplexing and Pin Assignments..................76
8.2 K53 Pinouts.......................................................................82
7 Dimensions...............................................................................75
K53 Sub-Family Data Sheet, Rev. 1, 6/2012.
4
Preliminary
General Business Information
Freescale Semiconductor, Inc.
Ordering parts
1 Ordering parts
1.1 Determining valid orderable parts
Valid orderable part numbers are provided on the web. To determine the orderable part
numbers for this device, go to
http://www.freescale.com
and perform a part number
search for the following device numbers: PK53 and MK53.
2 Part identification
2.1 Description
Part numbers for the chip have fields that identify the specific part. You can use the
values of these fields to determine the specific part you have received.
2.2 Format
Part numbers for this device have the following format:
Q K## A M FFF R T PP CC N
2.3 Fields
This table lists the possible values for each field in the part number (not all combinations
are valid):
Field
Q
K##
A
M
Qualification status
Kinetis family
Key attribute
Flash memory type
Description
Values
• M = Fully qualified, general market flow
• P = Prequalification
• K53
• D = Cortex-M4 w/ DSP
• F = Cortex-M4 w/ DSP and FPU
• N = Program flash only
• X = Program flash and FlexMemory
Table continues on the next page...
