MMSD–05–20–L–04.25–D–K–LUX
F-209-1
MMSS–10–20–L–03.25–D–K–LUS
IPD1–05–D–K–M
MINI MATE CABLE
MMSD, MMSS, IPD1 SERIES
Mates with:
IPL1 (Does not
mate with IPT1)
®
TYPE
PINS PER
ROW
WIRE
GAUGE
PLATING
OPTION
ASSEMBLY
LENGTH
END
OPTION
K
LATCH
OPTION
SPECIFICATIONS
For complete specifications
see www.samtec.com?MMSD,
www.samtec.com?MMSS or
www.samtec.com?IPD1
Insulator Material:
Nylon 66
Contact Material:
Phosphor Bronze
Plating:Au
or Sn over
50µ" (1,27µm) Ni
Operating Temp Range:
-55°C to +105°C (20-26 AWG)
-55°C to +80°C (28-30 AWG)
-55°C to +125°C (*Teflon
®
)
Voltage Rating:
675 VAC
Wire:
20 to 30 AWG
RoHS Compliant:
Yes
CURRENT RATING
AMBIENT TEMP MMSD/IPL1
20°C
7.4A
40°C
6.5A
60°C
5.9A
95°C
3.8A
6 POSITIONS (2x3)
20 AWG POWERED
MMSD
= Double Row
PVC Cable
MMSDT
= Double Row
*Teflon
®
Cable
MMSS
= Single Row
PVC Cable
–02,
–05,
–10,
–15,
–16,
–20,
–25
No. of positions
x (2,54) .100
+ (1,40) .055
25
01
–20
–22
–24
–24C
= Color
Coded
Cable
–L
= 10µ"
(0,25µm)
Gold on
contact,
Matte Tin
on tail
–“XX.XX”
= Assembly
Length in
Inches
(82,55mm)
03.25" min.
–D–K–MUS
–S
= Single End
–K
= Keyed
Polarization
–D
= Double End
(Latch Required)
MMSST
= Single Row
*Teflon
®
Cable
*Teflon
®
is a
trademark
of Dupont.
–26
–28
–30
(8,89)
.350
Metal Latches
–M
= Single Ended,for plastic)
(Leave blank
Double Ended (–D) Crossed requires MMSD
(2,54)
(2,54) .100 .100
–M & –MXX
(MMSD)
Assembly
Length
± (3,18)
.125
(12,83)
.505
APPLICATION
SPECIFIC OPTION
• Other color coded cables
(*Teflon
®
N/A).
• Other sizes/pin counts.
• With or without Plug
Polarization (omit pin 1).
Call Samtec.
MMSS
MMSD
–D–K–LUS
–LUS
= Plastic Latch up, straight
–LDS
= Plastic Latch down, straight
–LUX
= Plastic Latch up, crossed
–LDX
= Plastic Latch down, crossed
–MUS
= Metal Latch up, straight
–MDS
= Metal Latch down, straight
–MUX
= Metal Latch up, crossed
–MDX
= Metal Latch down, crossed
TYPE
POSITIONS
PER ROW
ROW
OPTION
K
LATCH
OPTION
TYPE
WIRE
GAUGE
01
PLATING
OPTION
APPLICATION
–24C CABLE
COLOR CODING
PIN
1
2
3
4
5
6
7
8
9
10
ETC
COLOR
BROWN
RED
ORANGE
YELLOW
GREEN
BLUE
VIOLET
GRAY
WHITE
BLACK
REPEAT
IPD1
= Body,
Loose
–02,
–05, –10,
–15, –16,
–20, –25
–S
= Single
Row
–K
= Keyed
Polarization
–L
CC79L
= Contact,
Loose
–2630
= 26 to 30 AWG
–D
= Double
Row
–M
= Metal Latch
(Leave blank for
plastic latch)
CC79R
= Contact,
Full Reel
(15,000
Parts
per Reel)
–2024
= 20 to 24 AWG
= 10µ"
(0,25µm)
Gold on
contact,
Matte Tin
on tail
(1,52)
.060
(17,93)
.706
(1,57)
.062
DIA
(3,81)
.150
(3,17)
.1250
Note:
For wiring option
information refer to drawing
on web.
Note:
Other Gold plating
options available.
Contact Samtec.
Note:
Some lengths, styles
and options are non-standard,
non-returnable.
HAND TOOLS
(12,83)
.505
(7,24)
.285
–D
–M
–S
20 to 24 AWG:
CAT-HT-179-2024-11
26 to 30 AWG:
CAT-HT-179-2630-11
(1,91)
.075
WWW.SAMTEC.COM
WWW.SAMTEC.COM
