Material
I/NO
1
2
3
DESCRIPTION
WAFER
PIN
HOOK
Phosphor Bronze, Tin-plated
Brass, Tin-plated
NYLON46 or PA6T, UL94V-0
MATERIAL
Available Pin
12505WR-02
12505WR-03
12505WR-04
12505WR-05
12505WR-06
12505WR-07
12505WR-08
12505WR-09
12505WR-10
12505WR-11
12505WR-12
12505WR-13
12505WR-14
12505WR-15
PARTS NO.
7.25
8.50
9.75
11.00
12.25
13.50
14.75
16.00
17.25
18.50
19.75
21.00
22.25
23.50
A
3.05
4.30
5.55
6.80
8.05
9.30
10.55
11.80
13.05
14.30
15.55
16.80
18.05
19.30
B
-
2.50
3.75
5.00
6.25
7.50
8.75
10.00
11.25
12.50
13.75
15.00
16.25
17.50
C
SECTION A - A'
Specification
Contact Resistance
Withstanding Voltage
Insulation Resistance
Applicable Wire
Applicable P.C.B
Applicable FPC/FFC
Solder Height
Crimp Tensile Strength
UL FILE NO
ITEM
Voltage Rating
Current Rating
Operating Temperature
SPEC
AC/DC 125V
AC/DC 1A
30m
Ω
MAX
AC250V/1min
-25
℃
~+85
℃
100M
Ω
MIN
-
0.8 ~ 1.6mm
-
0.15mm
-
E108706
PCB LAYOUT (12505WR-NN)
PCB ASS‘Y (12505WR-NN)
Yeonho Electronics
http://www.yeonho.com
