16.0Amp
Full Pack Glass Passivated
Super Fast
Recovery Rectifiers
Description
Mechanical Dimensions
UFF16C10~1660
ITO-220AB
DIMENSION IN MM
Devices connected type preffix add C----common cathode, A-----common Anode, D----Series connected
A
C
C
C
A
C
A
C
A
UFF16CXXC
UFF16CXXD
UFF16CXXA
Features
Low Forward Voltage Drop
High Current Capability
High Reliability
High Surge Current Capability
Mechanical Data
Case Molded Plastic
* Epoxy: UL 94-0 Rate Flame Retardant
Lead, Solderable per MIL-STD-202,
Method 208 Guaranteed
Weight:
1.35
grams
UFF16C20
UFF16C30
UFF16C40
UFF16C50
UFF16C60
Max Ratings 25C
Peak Repetitive Reverse Voltage
working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Forward Rectified
Current per leg Tc=150C @ Rated
Vdc
Repetitive Peak Forward Surge
Current @ Rated Vdc Square
Wave, 20KHz, Tc=150C
Non-Repetitive Peak Forward
Surge Current @ Rated Load
Cond., 1/2 Wave, Single Phase,
60Hz
Operating & torage Temp. Range
Max Forward Voltage @
If=8Amps, PW=300us, Tc=25C
Max DC Reverse Current @ Rated
DC Blocking Voltage Tc=125C /
Tc=25C
Max. Reverse Recovery Time @
If=0.5A, Ir=1A, Irr=0.25A
Typical Thermal Resisistance
Junction to Case
Symbol
Vrrm
Vrwm
Vdc
Vr(rms)
IF(av)
Ifm
UFF16C10
UNITS
100
100
100
70
16
16
200
200
200
140
16
16
300
300
300
210
16
16
400
400
400
280
16
16
500
500
500
350
16
16
600
600
600
420
16
16
V
V
V
V
A
A
Ifsm
Tj/Ts
Vf
Ir
Trr
Rthjc
35
35
35
0.975
0.975
125
-65~+150
1.3
10
50
1.5
50
50
1.3
1.5
1.5
A
C
A
uA
nA
C/W
16.0Amp
Full Pack Glass Passivated
Super Fast
Recovery Rectifiers
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
20
100
I
(AV)
, AVERAGE FORWARD CURRENT (A)
16
10
12
8
1.0
4
Resistive or
inductive load
0
100
125
150
175
T
C
, CASE TEMPERATURE (°C)
Fig. 1 Forward Current Derating Curve
0.1
0.2
0.6
1.0
1.4
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics per Element
I
FSM
, PEAK FORWARD SURGE CURRENT (A)
150
8.3ms single half-sine-wave
JEDEC method
400
T
j
= 25°C
125
C
T
, CAPACITANCE (pF)
100
100
75
50
25
10
0
1
10
NUMBER OF CYCLES AT 60Hz
Fig. 3 Max Non-Repetitive Surge Current
100
0.1
1.0
10
100
V
R
, REVERSE VOLTAGE (V)
Fig. 4 Typical Total Capacitance per Element
I
R
, INSTANTANEOUS REVERSE CURRENT (mA)
100
10
T
C
= 100°C
1.0
T
C
= 75°C
0.1
T
C
= 25°C
0.01
0
40
80
120
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
Fig. 5 Typical Reverse Characteristics
