UNISONIC TECHNOLOGIES CO., LTD
MMBT9015
PRE-AMPLIFIER, LOW LEVEL
& LOW NOISE
FEATURES
*High total power dissipation. (450mW)
*Excellent h
FE
linearity.
*Complementary to UTC MMBT9014
PNP SILICON TRANSISTOR
ORDERING INFORMATION
Ordering Number
Lead Free
Halogen Free
MMBT9015L-x-AE3-R
MMBT9015G-x-AE3-R
Package
SOT-23
Pin Assignment
1
2
3
E
B
C
Packing
Tape Reel
MARKING
www.unisonic.com.tw
Copyright © 2011 Unisonic Technologies Co., Ltd
1 of 2
QW-R206-023.Ba
MMBT9015
PNP SILICON TRANSISTOR
ABSOLUTE MAXIMUM RATINGS
(T
A
=25°C, unless otherwise specified)
PARAMETER
SYMBOL
RATINGS
UNIT
-45
Collector-Emitter Voltage
V
CEO
V
-50
Collector-Base Voltage
V
CBO
V
-5
Emitter Base Voltage
V
EBO
V
-100
Collector Current
I
C
mA
Collector dissipation
P
C
225
mW
Junction Temperature
T
J
150
°C
Storage Temperature
T
STG
-55 ~ +150
°C
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
ELECTRICAL CHARACTERISTICS
(T
A
=25°C, unless otherwise specified)
PARAMETER
Collector-Emitter Voltage
Collector-Base Voltage
Emitter Base Voltage
Collector cutoff current
Emitter Cutoff Current
DC Current Gain
Collector-Emitter Saturation Voltage
Base-Emitter Saturation Voltage
Base-emitter on voltage
Current-Gain-Bandwidth Product
Output Capacitance
Noise Figure
SYMBOL
V
CEO
V
CBO
V
EBO
I
CBO
I
EBO
h
FE
V
CE(SAT)
V
BE(SAT)
V
BE(ON)
f
T
C
OB
NF
TEST CONDITIONS
I
C
=-100μA, I
E
=0
I
C
=-1mA, I
B
=0
I
E
=-100μA, I
C
=0
V
CB
=-50V, I
E
=0
V
EB
=-5V, I
C
=0
V
CE
=-5V,Ic=-1mA
I
C
=-100mA, I
B
=-5mA
I
C
=-100mA, I
B
=-5mA
V
CE
=-5V, I
C
=-2mA
V
CE
=-5V, I
C
=-10mA
V
CB
=-10V, I
E
=0, f=1MHz
V
CE
=-5V,I
C
=-0.2mA,f=1KHz,R
S
=-1KΩ
MIN
-50
-45
-5
MAX UNIT
V
V
V
-50
nA
-100 nA
200 600
-0.2 -0.7
V
-0.82 -1.0
V
-0.65 -0.75 V
190
MHz
4.5
7.0
pF
0.7
10
dB
TYP
60
-0.6
100
CLASSIFICATION OF h
FE
RANK
RANGE
A
60-150
B
100-300
C
200-600
UTC assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or
other parameters) listed in products specifications of any and all UTC products described or contained
herein. UTC products are not designed for use in life support appliances, devices or systems where
malfunction of these products can be reasonably expected to result in personal injury. Reproduction in
whole or in part is prohibited without the prior written consent of the copyright owner. The information
presented in this document does not form part of any quotation or contract, is believed to be accurate
and reliable and may be changed without notice.
