PRELIMINARY
HIGH POWER WIREWOUND RESISTORS
TUBULAR, 5 WATT to 500 WATT
RESISTORS
wCOILS wDELA
LINES
Y
TL SERIES
r
r
r
r
r
r
r
FEATURES
Widest range in the industry!
High performance for low cost.
Tolerances up to ±1.0%
Tapped and adjustable construction available.
Custom sizes and terminations available.
Flat version available.
Mounting hardware available.
→ ←
H
↓
↑
L
←
D
→
á
d
â
OPTIONS
r
OPTION X
--
Non-Inductive
r
OPTION ER
--
100 hour burn-in
RCD
Type
Wattage Resistanc e
Max.
@ 2 5°C
Range*
Voltage
W
→
←
→ ←
h
Dim ensions in inches [mm ]
L
D**
d (Core I.D.)
W
H
h
TL5
TL8
TL12
TL20
TL25
TL50
TL75
TL100
TL150
TL200
TL300
TL500
5W
8W
12W
20W
25W
50W
75W
100W
150W
200W
300W
500W
5K
10K
27K
33K
36K
100K
100K
150K
200K
250K
330K
500K
200V
250V
500V
600V
750V
1200V
2000V
2500V
3000V
4500V
5000V
5000V
.78±.062 [19.8±1.57]
1.00±.062 [25.4±1.57]
1.75±.062 [44.5±1.57]
2.00±.062 [50.8±1.57]
2.00±.062 [50.8±1.57]
.40 [10.2] .187±.032 [4.75±.813] .16 [4.06]
.40 [10.2] .187±.032 [4.75±.813] .16 [4.06]
.40 [10.2] .187±.032 [4.75±.813] .16 [4.06]
.59 [15]
.312±.062[7.92±1.57] .16 [4.06]
.68 [17.3] .344±.062 [8.74±1.57] .16 [4.06]
.32 [8.13]
.32 [8.13]
.32 [8.13]
.32 [8.13]
.32 [8.13]
.50 [12.7]
.32 [8.13]
.32 [8.13]
.38 [9.65]
.40 [10.2]
.40 [10.2]
.50 [12.7]
.60 [15.2]
.60 [15.2]
.60 [15.2]
.60 [15.2]
.60 [15.2]
1.38 [35.1]
.08 [2.03]
.08 [2.03]
.08 [2.03]
.08 [2.03]
.08 [2.03]
.08 [2.03]
.173 [4.39]
.173 [4.39]
.173 [4.39]
.173 [4.39]
.173 [4.39]
.217 [5.51]
4.00±.125 [101.6±3.18] .75 [19.1] .344±.062 [8.74±1.57] .20 [5.08]
4.00±.125 [101.6±3.18] 1.25 [31.8] .750±.062 [19±1.57]
6.00±.25 [152.4±6.35] 1.25 [31.8] .750±.062 [19±1.57]
7.875±.25 [200±6.35]
1.25 [31.8] .750±.062 [19±1.57]
9.85±.25 [250.2±6.35] 1.25 [31.8] .750±.062 [19±1.57]
12.00±.25 [304.8±6.35] 1.25 [31.8] .750±.062 [19±1.57]
12.75±.25 [323.9±6.35] 2.16 [54.9]
1.350 [34.3] Min.
* Available as low as 0.01W on special order
**Typ. O.D. over coating
MODIFICATIONS
TLA
TLA Series - Axial Lead
TLR Series - Radial Lead
TL Series resistors are available
with lead wires for soldering direct
to PC board. The resistor body can
be supported by leads up to 25W
size, Type TLA has axial leads (as
pictured), Type TLR has radial
leads.
X
TLV Series - Adjustable
Feature a track of exposed wire
which enables adjustment of
resistance value. The slider
divides the wattage rating in direct
proportion to the divided resis-
tance. Due to the use of heavier
wire sizes, the maximum resis-
tance of the TLV Series is 33% of
the standard TL Series.
TLT Series - Tapped
Multi-section or tapped resistors
are available for voltage divider
applications. Power rating is
reduced due to reduction in
winding space. Indicate the
wattage required per section when
ordering.
SPECIFICATIONS
Tolerance
Temperature Coefficient
Dielectric Strength
Overload
Derating
±5% is standard 1
W
and above,
±10% below 1
W
(avail. to ±1%)
50ppm/°C Typ. 1
W
and above,
90ppm/°C 0.1
W
to 0.99
W
1000 VAC (terminal to mounting bracket)
10x rated power for 5 sec.
Full power @ 25°C to zero power @ 350°C
P/N DESIGNATION:
TLA 12
RCD Type:
TL, TLA, TLR, TLV, TLT
Size
Options:
X, ER
(leave blank for standard)
4-Digit Resis. Code:
3 signif. digits & multiplier
(R100=0.1Ω, 1R00=1Ω, 1000=100Ω, 1001=1KΩ,
1002=10KΩ, 1003=100KΩ)
Tolerance Code:
K=10%, J=5%, H=3%, G=2%, F=1%
Packaging:
B = Bulk
- 1R00 - J B
RCD Components Inc.,
520 E. Industrial Park Dr., Manchester, NH USA 03109
Tel: (603) 669-0054 Fax:(603) 669-5455 E-mail: rcdcompinc@aol.com www.rcd-comp.com
FAXXX specifications subject to change without notice
