Shielded Surface Mount Power Inductors
SERIES S3483R - SHIELDED FERRITE CORE & SLEEVE
1.0
1.5
2.2
3.3
4.7
6.8
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
56.0
68.0
82.0
100.0
150.0
220.0
330.0
470.0
680.0
1000.0
0.019
0.023
0.025
0.028
0.044
0.050
0.064
0.080
0.090
0.120
0.132
0.175
0.192
0.250
0.288
0.340
0.372
0.480
0.540
0.780
1.260
2.010
2.460
3.780
5.740
3.12
3.00
2.10
1.90
1.70
1.60
1.40
1.25
1.10
1.00
0.96
0.84
0.75
0.70
0.67
0.62
0.59
0.50
0.45
0.37
0.29
0.22
0.20
0.16
0.13
R*
Actual Size
Physical Parameters
Inches
A
0.276 to 0.283
B
0.276 to 0.283
C
0.114 to 0.138
D
0.067 to 0.091
E
0.201 to 0.224
F
0.035 Nominal
Millimeters
7.00 to 7.20
7.00 to 7.20
2.90 to 3.50
1.70 to 2.30
5.10 to 5.70
0.89 Nominal
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
Operating Temperature Range
–20°C to +85°C
Inductance:
Measured with no DC current at 100 kHz
Current Rating at +25° Ambient
40°C temperature rise maximum.
DC that will decrease the inductance by 10% maximum.
Final Termination Finish
100% Matte Tin (Sn)
Marking
Components are marked with three characters.
In the instance of two digits and a letter R, the R indicates
a decimal point and the remaining digits indicates the
inductance in uH. When three digits are present, the first
two digits indicate the inductance in uH and the third digit
indicates the number of trailing zeros where a zero
indicates that there are no trailing zeros.
Example: S3483R-101M (100 H)
101
Packaging
Tape and Reel
(12mm): 13" reel, 1000 pieces max.; 7" reel not available.
