SERIES
5393R
5393
s
or
ct
du
In
DA
SH
NU
MB
High Current Radial Leaded Chokes
ER
*
-504K
-204K
-603K
-154K
-393K
-923K
-503K
-243K
SERIES 5393R AND 5393R
500
0.050
0.8
200
0.021
1.2
60
0.0085
1.9
150
0.0130
2.1
39
0.0048
2.5
92
0.0075
2.9
50
0.0045
3.1
24
0.0025
5.7
15.0
20.0
28.0
30.0
40.0
45.0
50.0
60.0
*Complete part # must include series # PLUS the dash #
For surface finish information,
refer to www.delevanfinishes.com
Shown Approximately
at 50% of Actual Size
Physical Parameters in Inches (Millimeters)
dash number
-504K
-204K
-603K
-154K
-393K
-923K
-503K
-243K
Type
1
2
2
2
2
2
1
2
Typ. Weight (grams)
305
310
160
470
210
650
420
270
A(Max.)
2.45 (62.23)
2.45 (62.23)
2.45 (62.23)
2.45 (62.23)
2.45 (62.23)
2.55 (64.77)
2.55 (64.77)
2.45 (62.23)
B ±0.062 (1.57)
1.45 (36.83)
1.45 (36.83)
1.02 (25.91)
1.65 (41.91)
1.15 (29.21)
1.92 (48.77)
1.57 (39.88)
1.27 (32.26)
C ±0.062 (1.57)
0.980 (24.89)
0.980 (24.89)
0.770 (19.56)
1.080 (27.43)
0.820 (20.83)
1.210 (24.89)
1.050 (26.67)
0.890 (22.61)
D ±0.062 (1.57)
1.95 (49.53)
-
-
-
-
-
2.10 (53.34)
-
(E) Lead Diameter
0.082
0.102
0.102
0.129
0.129
0.162
0.162
0.162
Operating Temperature Range
-55°C to +125°C
(-55°C to +75°C @ full current)
Current Rating at 75°C Ambient
50°C Temperature Rise
Maximum Power Dissipation at +85°C
1.166 Watts Maximum
Inductance
Measured @ 1 kHz with 0 ADC on Wayne Kerr 3245A,
or equivalent.
Incremental Current
The amount of DC that decreases the inductance by
10% maximum relative to the 0 ADC.
Dielectric Withstanding Voltage
2500 Vrms Minimum winding to outside cover
1/4” from winding edge
Marking
Delevan, 5393 or 5393R, dash number (per table) and inductance
tolerance letter
Leads
Solder coated to within 1/8 inch of body
Mechanical Configuration
Self leaded terminals, coated coil, shrink sleeve
encapsulated
Packaging
Bulk only
