DATA SHEET
RECEIVER
NR3312 Series
InGaAs PIN-PD RECEIVER WITH INTERNAL PRE-AMPLIFIER
FOR 10 Gb/s APPLICATIONS
DESCRIPTION
The NR3312 Series products consist of InGaAs PIN ROSAs (Receiver
Optical Sub-Assembly) with internal pre-amplifiers designed for 10 Gb/s
optical transceivers such as the XENPAK/X2/XFP. These modules are ideal
as receivers for IEEE 10G BASE and SONET OC-192 systems.
NR3312TG
FEATURES
• XMD-MSA compliant ROSA
• 10 Gb/s high sensitivity InGaAs PIN-PD
• +3.3 V SiGe transimpedance pre-amplifier
• Minimum receiver sensitivity
• Operating case temperature
• Transimpedance
• Cut-off frequency
• With flexible printed circuit
P
r
=
−20
dBm
T
C
=
−5
to +85°C
Z
t
= 2 000
Ω
(Single-ended)
fc = 11 GHz
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all products and/or types are available in every country. Please check with an NEC Electronics
sales representative for availability and additional information.
Document No. PL10638EJ02V0DS (2nd edition)
Date Published March 2010 NS
Printed in Japan
The mark <R> shows major revised points.
2006, 2010
The revised points can be easily searched by copying an "<R>" in the PDF file and specifying it in the "Find what:" field.
