C252010HPB-1R5 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> inductor> C252010HPB-1R5

C252010HPB-1R5: DescriptionSMD Power Inductor; CategoryPassive components inductor; File Size260KB，3 Pages; ManufacturerSUMIDA; Websitehttp://www.sumida.com/; Environmental Compliance

Download Datasheet Parametric View All

C252010HPB-1R5 Overview

SMD Power Inductor

C252010HPB-1R5 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	SUMIDA
Reach Compliance Code	unknown
ECCN code	EAR99
Inductor type	GENERAL PURPOSE INDUCTOR

Preview

Download Datasheet

View All

SMD Power Inductor

C252010/DS

Description

• Multilayer power inductor.

• Magnetically shielded.

• L W H: 2.65 2.15 1.0 mm Max.

• Product weight: 23mg (Ref.)

• Moisture Sensitivity Level: 1

• RoHS compliance.

• Halogen Free available.

Environmental Data

• Operating temperature range: -30

+85

(including coil’s self temperature rise)

+85

• Storage temperature range: -30

• Solder reflow temperature: 260

peak.

Packaging

• Carrier tape and reel packaging.

RoHS

Halogen

Free

Dimension - [mm]

2.0±64.0

.xaM 0.1

51.0±5.2

Land pattern and Schematics - [mm]

6.0

3.1

Applications

• Ideally used in DC/DC converters for Smart

phones, Cell phones, other portable instruments,

HDD, and SSD.

Electrical Characteristics

C252010HPB-1R5

C252010HPB-2R2

C252010HPB-3R3

C252010HPB-4R7

C252010LDB-1R0

C252010LDB-2R2

C252010LDB-4R7

C252010WB-1R0

C252010WB-3R3

C252010WB-4R7

1.5

110

1200

1400

800

700

1500

800

300

1700

1000

800

1700

1200

1000

1700

1400

1300

1900

1000

900

2.2

3.3

4.7

1.0

2.2

4.7

1.0

3.3

4.7

180

270

105

145

165

230

320

1. Inductance measuring condition: at 3MHz.

2. Saturation current: The value of D.C. current when the inductance decreases to 70% of it’s nominal value.

3. Temperature rise current: The value of D.C. current when the temperature rise is t 40 (Ta 25 ).

Page 1 of 3

Revised: 19-Mar-12

※

℃ ＝ ℃ ＝△

※

Part No.

L( H)

20% 1

D.C.R. (m

25%

)

Saturation current

(mA) 2

Temperature rise

Current (mA) 3

℃

℃ ½℃

× ×
