Series 72
Guardian
How To Order
D
713-353
t transition
T transition with self-locking feature for ease of assembly and repair for multi-legged
conduit assemblies. Use H code conduit fittings to interface.
Product
Series
Finish
(Table II)
PFTE Teflon Coating
(Omit for none)
713
-
353 M
Basic No.
09
Dash No.
(Table I)
P
*
B TyP
C
table ii
Sym
C
material
Finish Description
M
MT
NF
ZN
A THrEAD
TyP
ZNU
Z1
Electroless Nickel
Nickel-PTFE
Cad/Olive Drab over Electroless
Nickel
Aluminum
Zinc Nickel/Olive Drab over
Electroless Nickel
Zinc Nickel/Black over
Electroless Nickel
Stainless
Passivate
Steel
table i
Dash No
09
11
13
15
17
19
21
23
25
33
37
Conduit Size
(Ref)
06,09
10,12
14,16
20
24
28
32
36
40
48
56
A Thread iso
metric
M12 X 1.0-6g
M15 X 1.0-6g
M18 X 1.0-6g
M22 X 1.0-6g
M25 X 1.0-6g
M28 X 1.0-6g
M31 X 1.0-6g
M34 X 1.0-6g
M37 X 1.0-6g
M45 X 1.5-6g
M50 X 1.5-6g
B Dia
.281
(7.1)
.397 (10.1)
.511
(13.0)
.636 (16.2)
.761 (19.3)
.875 (22.2)
1.000 (25.4)
1.125 (28.6)
1.250 (31.8)
1.530 (38.9)
1.750 (44.5)
C max
.78
.90
.94
1.00
1.08
1.13
1.19
1.25
1.31
1.49
1.62
(19.8)
(22.9)
(23.9)
(25.4)
(27.4)
(28.7)
(30.2)
(31.8)
(33.3)
(37.8)
(41.1)
D max
1.53
1.71
1.84
1.96
2.12
2.23
2.34
2.46
2.59
2.95
3.21
(38.9)
(43.4)
(46.7)
(49.8)
(53.8)
(56.6)
(59.4)
(62.5)
(65.8)
(74.9)
(81.5)
Material and Finish
See Table II.
*Internal Surface coated with Teflon as shown, see P/N development.
©2011 Glenair, Inc.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
36
