HMC305LP4_10

Description
0.5 dB LSB GaAs MMIC 5-BIT SERIAL CONTROL DIGITAL ATTENUATOR, 0.7 - 3.8 GHz
File Size352KB,8 Pages
ManufacturerHittite Microwave(ADI)
Websitehttp://www.hittite.com/
Download Datasheet Compare View All

HMC305LP4_10 Overview

0.5 dB LSB GaAs MMIC 5-BIT SERIAL CONTROL DIGITAL ATTENUATOR, 0.7 - 3.8 GHz

HMC305LP4
/
305LP4E
v03.0809
5
ATTENUATORS - DIGITAL - SMT
Typical Applications
• Cellular/3G Infrastructure
The HMC305LP4 / HMC305LP4E is ideal for:
• Fixed Wireless, WiMax & WiBro
• Test Instrumentation
Functional Diagram
D
E
U
IN
T
N
O
T
C
C
S
U
I
D
D
O
R
P
Features
0.5 dB LSB Steps to 15.5 dB
CMOS Compatible Serial Data Interface
SPI Compatible Serial Output
±0.3 dB Typical Bit Error
2
0.5 dB LSB GaAs MMIC 5-BIT SERIAL
CONTROL DIGITAL ATTENUATOR, 0.7 - 3.8 GHz
s
ign
24 Lead 4x4mm QFN Package:
s
De
16mm
Included in the HMC-DK004 Designer’s Kit
New
for
ded
Description
General
men
m
The HMC305LP4 & HMC305LP4E are broadband
eco
tR
5-bit positive control GaAs IC digital attenuators with
No
CMOS compatible serial-to-parallel drivers packaged
in leadless QFN 4x4 mm SMT packages. Covering
0.7 to 3.8 GHz, the insertion loss is typically less
than 1.5 to 2 dB. The attenuator bit values are 0.5
(LSB), 1, 2, 4, and 8 dB for a total attenuation of
15.5 dB. Attenuation accuracy is excellent at ±0.25
dB typical with an IIP3 of up to +52 dBm. Five bit
serial control words are used to select each attenuation
state. A single Vcc bias of +3V to +5V applied through
an external 5k Ohm resistor is required.
Electrical Specifi cations,
T
A
= +25° C, Vcc = +3V to +5V
Parameter
Frequency
0.7 - 1.4 GHz
1.4 - 2.3 GHz
2.3 - 2.7 GHz
2.7 - 3.8 GHz
0.7 - 3.8 GHz
0.7 - 1.4 GHz
1.4 - 2.3 GHz
2.3 - 2.7 GHz
2.7 - 3.8 GHz
0.7 - 0.9 GHz
0.9 - 2.2 GHz
2.2 - 3.8 GHz
Vcc = 5V
Vcc = 3V
Vcc = 5V
Vcc = 3V
0.7 - 3.8 GHz
0.7 - 3.8 GHz
Min.
Typical
1.2
1.5
1.8
2.0
15.5
17
18
19
15
± (0.5 +5% of Atten. Setting) Max
± (0.3 +4% of Atten. Setting) Max
± (0.5 +5% of Atten. Setting) Max
25
23
52
48
750
830
Max.
1.5
2.0
2.3
2.5
Units
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dBm
dBm
dBm
dBm
ns
ns
Insertion Loss
Attenuation Range
Return Loss (RF1 & RF2, All Atten. States)
Attenuation Accuracy: (Referenced to Insertion Loss)
All Attenuation States
Input Power for 0.1 dB Compression
Input Third Order Intercept Point
(Two-tone Input Power = 0 dBm Each Tone)
Switching Characteristics
tRISE, tFALL (10/90% RF)
tON, tOFF (Latch Enable to 10/90% RF)
0.7 - 3.8 GHz
5-2
For price, delivery, and to place orders, please contact Hittite Microwave Corporation:
20 Alpha Road, Chelmsford, MA 01824 Phone: 978-250-3343 Fax: 978-250-3373
Order On-line at www.hittite.com
