Compact Chip Resistor Networks
MNR14 (06034 size)
Features
1) Convex electrodes
Easy to check the fillet after soldering is finished.
2) Small, light, rectangular 4-chip network
Area ratio is 65% smaller than that of MNR34, while weight ratio has been cut 75%.
3) High-density mounting
Can be mounted even more densely than four 0603 chips (MCR03), and mounting costs are lower.
4) Compatible with a wide range of mounting equipment.
Squared coners make it excellent for mounting using image recognition machines.
5) ROHM resistors have approved ISO9001- / ISO/TS 16949- certification.
Design and specifications are subject to change without notice. Carefully check the specification sheet supplied with the
product before using or ordering it.
Ratings
Item
Rated power
Conditions
Power must be derated according to the power derating curve in
Figure 1 when ambient temperature exceeds 70°C.
100
POWER LOAD (%)
Specifications
0.063W (1 / 16W)
at 70°C
80
60
40
20
0
−55
0
70
100
125
AMBIENT TEMPERATURE (°C)
Fig.1
Rated voltage
The voltage rating is calculated by the following equation. If the value
obtained exceeds the limiting element voltage, the voltage rating
is equal to the maximum operating voltage.
E: Rated voltage (V)
E=
P×R
P: Rated power (W)
R: Nominal resistance (Ω)
Nominal resistance
Operating temperature
See Table 1.
−55°C
to
+155°C
Limiting element voltage
50V
Jumper type
Resistance
Rated current
Max. 50mΩ
1A
Table 1
Resistance tolerance
Resistance range
(Ω)
Resistance temperature coefficient
(ppm /
°C)
Operating temperature
−55°C
to
+155°C
J (±5%)
F (±1%)
2.2 to 9.1 (E6)
10 to 1M (E24)
10 to 1M (E24)
±500
±200
±100
Before
using components in circuits where they will be exposed to transients such as pulse loads (short-duration, high-level loads), be certain to evaluate the
component in the mounted state. In addition, the reliability and performance of this component cannot be guaranteed if it is used with a steady state voltage that
is greater than its rated voltage.
www.rohm.com
c
○
2011 ROHM Co., Ltd. All rights reserved.
1/3
2011.12 - Rev.H
MNR14 (06034 size)
Characteristics
Item
Resistance
Variation of resistance
with temperature
Overload
±
(2.0%+0.1Ω)
Guaranteed value
Resistor type
Jumper type
J :
±5%
F :
±1%
Max. 50mΩ
See Table.1
Max. 50mΩ
Test conditions (JIS C 5201-1)
JIS C 5201-1 4.5
JIS C 5201-1 4.8
Measurement :
−55
/
+25
/
+125°C
JIS C 5201-1 4.13
Rated voltage (current)
×2.5,
2s.
Maximum Overload Voltage : 100V
JIS C 5201-1 4.17
Rosin·Ethanol (25%WT)
Soldering condition : 235±5°C
Duration of immersion : 2.0±0.5s.
JIS C 5201-1 4.18
Soldering condition : 260±5°C
Duration of immersion : 10±1s.
JIS C 5201-1 4.19
Test temp. :
−55°C
to
+125°C
5cyc
JIS C 5201-1 4.24
40°C, 93%RH
Test time : 1,000h to 1,048h
JIS C 5201-1 4.25.1
Rated voltage (current), 70°C
1.5h : ON
−
0.5h : OFF
Test time : 1,000h to 1,048h
JIS C 5201-1 4.25.3
125°C
Test time : 1,000h to 1,048h
JIS C 5201-1 4.29
23±5°C, Immersion cleaning, 5±0.5min.
Solvent : 2-propanol
JIS C 5201-1 4.33
Data Sheet
Solderability
A new uniform coating of minimum of
95% of the surface being immersed
and no soldering damage.
±
(1.0%+0.05Ω)
Max. 50mΩ
No remarkable abnormality on the appearance.
±
(1.0%+0.05Ω)
±
(3.0%+0.1Ω)
Max. 50mΩ
Max. 100mΩ
Resistance to
soldering heat
Rapid change of
temperature
Damp heat, steady state
±
(3.0%+0.1Ω)
Endurance at 70°C
±
(3.0%+0.1Ω)
Max. 100mΩ
Max. 100mΩ
Endurance
±
(1.0%+0.05Ω)
Resistance to solvent
Max. 50mΩ
Bend strength of
the end face plating
±
(1.0%+0.05Ω)
Max. 50mΩ
Without mechanical damage such as breaks.
Dimensions
(Unit : mm)
0.6±0.15
0.4±0.15
0.3±0.2
Material
0.25±0.15
0.3±0.2
1
0.3±0.2
103
0.8
3.2±0.1
0.5±0.1
1.6±0.1
Resistive element
(Oxide metal thick film)
Silver thick film electrode
Nickel electrode
Sn electrode
Alumina substrate
Overcoating (Resin)
2
3
4
2
3
4
5
6
Cross section A-A'
6
1
5
Cross section B-B'
6 1
∗
Marking may change to the one-character type.
∗∗
Pitch of the upper electrode.
5
Equivalent
circuit
R1
R2
R3
R4
R1=R2=R3=R4
www.rohm.com
c
○
2011 ROHM Co., Ltd. All rights reserved.
2/3
2011.12 - Rev.H
