100mA/50V Digital transistors(with built-in resistors)
DTC014EM / DTC014EEB / DTC014EUB
Features
1) Built-in bias resistors enable the configuration of
an inverter circuit without connecting external input resistors.
(See equivalent circuit)
2) The bias resistors consist of thin-film resistors with complete
isolation to allow negative biasing of the input.
They also have the advantage of almost completely
eliminating parasitic effects.
3) Only the on/off conditions need to be set for operation,
making the device design easy.
Dimensions
(Unit : mm)
VMT3
Abbreviated symbol : 40
EMT3F
(3)
Structure
NPN epitaxial planar silicon transistor
(Resistor built-in type)
UMT3F
(1)
(2)
Abbreviated symbol : 40
1.25
2.1
Applications
Inverter, Interface, Driver
0.32
2.0
0.9
0.53
0.425
(3)
(1)
0.65 0.65
1.3
(2)
0.13
Abbreviated symbol : 40
Packaging
specifications
Package
Packaging Type
Type
Code
Basic ordering
unit (pieces)
DTC014EM
DTC014EEB
DTC014EUB
Equivalent
circuit
VMT3
Taping
T2L
8000
○
-
-
EMT3F
Taping
TL
3000
-
○
-
UMT3F
Taping
TL
3000
-
-
○
IN
R
1
IN
R
2
GND
OUT
OUT
GND
R
1
=R
2
=10kΩ
Absolute
maximum
(Ta=25C)
Parameter
Supply voltage
Input voltage
Collector current *1
Output current
Power dissipation *2
Junction temperature
Range of storage temperature
*1 Characteristics of built-in transistor
*2 Each terminal mounted on a reference land
Symbol
V
CC
V
IN
I
C(max)
I
O
P
D
Tj
Tstg
M
Limits(DTC014E□)
EB
UB
50
40
-10
100
50
150
150
-55 to +150
200
Unit
V
V
V
mA
mA
mW
℃
℃
www.rohm.com
©2011 ROHM Co., Ltd. All rights reserved.
1/2
2011.08 - Rev.A
0.53
0.425
