ECS-VX0-97
SMD VOLTAGE CONTROLLED CRYSTAL OSCILLATOR
The ECS-VXO-97 offers the frequency control
of a VCXO in a SMD, ceramic package.
Frequency can be pulled up to ± 100 ppm by
varying the control voltage of 2.5V by up to
±2.0V.
FEATURES
• 2.0 mm low profile
• Waveform symmetry of 40/60%
• SMD version
• 3.3V operation (optional)
• Tape & Reel (1000 pcs)
• PbFree/RoHS Compliant
PART NUMBERING GUIDE
“EXAMPLE”
PART NUMBER
ECS-VXO-97
–
FREQUENCY (16.0 MHz)
160
–
FREQUENCY CONTROL RANGE
A
OPERATING CONDITIONS/ELECTRICAL CHARACTERISTICS
PARAMETERS
FREQUENCY RANGE
FREQUENCY STABILITY
(A)
(B)
(C)
OPERATING TEMPERATURE
STORAGE TEMPERATURE
INPUT VOLTAGE (V
CC)
CONTROL VOLTAGE (V
C)
INPUT CURRENT
SYMMETRY
RISE AND FALL TIMES
“0” LEVEL
“1” LEVEL
LOAD
FREQUENCY LINEARITY
RISE AND FALL TIMES
CONTROL
RANGE
CONDITIONS
F
O
All conditions
VC = +2.5 VDC ±2.0V
VC = +2.5 VDC ±2.0V
VC = +2.5 VDC ±2.0V
T
OPR
T
STG
MINIMUM
8.000
-30
-50
-75
-100
-10
-30
+4.75
+0.5
40/60
TYPICAL
+5
+2.5
50 ±10
OUTPUT
(-10˚ TO +70˚C)
at 1/2 V
CC
Level
MAXIMUM
40.000
+30
+50
+75
+100
+60
+85
+5.25
+4.5
25
60/40
10
V
CC
x 0.1V
15
+10
10
V
CC
x 0.9V
HCMOS
-10
UNITS
MHz
PPM
PPM
PPM
PPM
˚C
˚C
V DC
V DC
mA
%
ns
V
V
pF
%
ms
PACKAGE DIMENSIONS (mm)
7.0
±0.2
5.0
±0.2
1.8
2.0
FREQUENCY
3.28
1.8
PIN CONNECTIONS
#1
V CONTROL
#2
GND
#3
OUTPUT
#4
VCC
PACKAGE DATA
COVER
METAL
BASE
CERAMIC
SEALING SEAM-WELD
TERMINAL
GOLD
PLATING
2.2
0.01µF
2.0
1.8
±0.2
5.08
Figure 2) Land Pattern
Test Point
#1
#2
1.2
V
CC
A
#4
#3
TR
TF
2.6
90% V
CC
1/2 V
CC
V
CC
OUTPUT
GND
#2
DC Power
Supply
V CONTROL
#4
#3
0.01µF
V
#1
CL
"0" Level
GND
10% 1/2 V
CC
t
T
0V DC
1.4
CL: Including fixture and probe capacitance.
Symmetry = 1/ T x 100(%)
Figure 1) ECS-VXO-97 – Top,
Side and Bottom views
Figure 3) Test Circuit
Figure 4) Output Wave Form
