DTC114YE / DTC114YUA
DTC114YCA / DTC114YSA
Elektronische Bauelemente
NPN Digital Transistors (Built-in Resistors)
RoHS Compliant Product
A suffix of “-C” specifies halogen & lead-free
FEATURES
Built-in bias resistors enable the configuration of an
inverter circuit without connecting external input
resistors (see equivalent circuit).
The bias resistors consist of thin-film resistors with
complete isolation to allow positive biasing of the
input. They also have the advantage of almost
completely eliminating parasitic effects.
Only the on/off conditions need to be set for
operation, making device design easy.
DTC114YE (SOT-523)
DTC114YUA (SOT-323)
Addreviated symbol：64
DTC114YCA (SOT-23)
Addreviated symbol：64
DTA114YSA (TO-92S)
EQUIVALENT CIRCUIT
Addreviated symbol：64
ABSOLUTE MAXIMUM RATINGS
(T
A
=25°C unless otherwise noted)
Limits (DTC1114Y□)
Parameter
Collector-Base Voltage
Input voltage
Output current
Power dissipation
Junction & Storage temperature
Symbol
E
V
CC
V
IN
I
O
I
C(MAX)
P
D
T
J
, T
STG
150
Unit
UA
50
-6~40
70
100
200
150, -55~150
300
CA
SA
V
V
mA
mW
°C
http://www.SeCoSGmbH.com/
Any changes of specification will not be informed individually.
06-Jan-2012 Rev.B
Page 1 of 2
DTC114YE / DTC114YUA
DTC114YCA / DTC114YSA
Elektronische Bauelemente
NPN Digital Transistors (Built-in Resistors)
ELECTRICAL CHARACTERISTICS
(T
A
=25°C unless otherwise noted)
Parameter
Input voltage
Output voltage
Input current
Output current
DC current gain
Input resistance
Resistance ratio
Transition frequency
Symbol
V
I(off)
V
I(on)
V
O(on)
I
I
I
O(off)
G
I
R
1
R
2
/ R
1
f
T
Min.
-
1.4
-
-
-
68
7
3.7
-
Typ.
-
-
-
-
-
-
10
4.7
250
Max.
0.3
-
0.3
0.88
0.5
-
13
5.7
-
Unit
V
V
mA
μA
Test Conditions
V
CC
=5V, I
O
=100μA
V
O
=0.3V, I
O
=1mA
I
O
/I
I
=5mA/0.25mA
V
I
=5V
V
CC
=50V, V
I
=0
V
O
=5V, I
O
=5mA
KΩ
MHz
V
O
=10V, I
O
=5mA,
f=100MHz
CHARACTERISTIC CURVES
