TOROIDAL INDUCTOR
P11T80B SERIES
• RoHS Compliant Product
• Operating Temp: -55°C to +105°C
• Inductance test @ 10KHz, 0.1V
RMS
• I
DC
:
∆30°C
temperature rise max at rated current
• Add -V for Vertical Mount, -H for Horizontal Mount after
part number
ELECTRICAL SPECIFICATION @ 25°C
P11T80B-
100-12.5
120-12
150-11.3
180-10.8
220-10.3
270-9.8
330-7.4
390-7.1
470-6.7
560-6.4
680-4.9
101-4.4
121-3.3
151-3.1
181-3.8
221-3.6
271-3.4
331-3.3
391-2.5
471-2.3
561-2.2
681-2.1
821-2.0
102-1.9
PART
NUMBER
L (µH)
±15%
10KHz 0.1V
RMS
10
12
15
18
22
27
33
39
47
56
68
100
120
150
180
220
270
330
390
470
560
680
820
1000
I
DC
(A)
12.5
12.0
11.3
10.8
10.3
9.8
7.4
7.1
6.7
6.4
4.9
4.4
3.3
3.1
3.8
3.6
3.4
3.3
2.5
2.3
2.2
2.1
2.0
1.9
L (µH)
±15%
@I
DC
6.7
7.9
9.6
11.3
13.4
16.0
21.6
25.0
29.3
34.1
45.7
64.0
84.4
102.7
105.9
125.6
149.4
176.8
235.3
275.9
320.1
377.2
441.5
521.3
R
DC
MAX
(
W
)
0.007
0.008
0.008
0.009
0.010
0.011
0.020
0.022
0.024
0.026
0.046
0.056
0.098
0.110
0.075
0.083
0.092
0.100
0.180
0.190
0.210
0.230
0.260
0.280
DIM
A
NOM
0.46
0.46
0.46
0.46
0.46
0.46
0.45
0.45
0.45
0.45
0.44
0.44
0.44
0.44
0.48
0.48
0.48
0.48
0.46
0.46
0.46
0.49
0.49
0.49
DIM
B
NOM
0.88
0.88
0.88
0.88
0.88
0.88
0.87
0.87
0.87
0.87
0.86
0.86
0.86
0.86
0.90
0.90
0.90
0.90
0.88
0.88
0.88
0.91
0.91
0.91
DIM
C
NOM
0.053
0.053
0.053
0.053
0.053
0.053
0.042
0.042
0.042
0.042
0.034
0.034
0.027
0.027
0.034
0.034
0.034
0.034
0.027
0.027
0.027
0.027
0.027
0.027
Mechanical
Schematic
Dimensions
Unless otherwise specified, all tolerances are:
inch: .XX : ± 0.008
.XXX : ±0.004
mm: X,X : ± 0,20 X,XX : ±0,10
Product performance is limited to specified parameter. Data is subject to change without prior notice.
P11T80B-XXX
0548JW
