LH1526AB, LH1526AAC, LH1526AACTR
www.vishay.com
Vishay Semiconductors
Dual 1 Form A Solid-State Relay
FEATURES
• Dual channel
• Extremely low operating current
1
8
S1
• High speed operation
• Isolation test voltage 5300 V
RMS
• Current limit protection
• Load voltage 400 V
• Load current 125 mA
• Clean bounce free switching
• Low power consumption
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
2
3
7
S1'
6
S2
4
5
S2'
DESCRIPTION
The LH1526 dual 1 Form A relays are SPST normally open
switches that can replace electromechanical relays in many
applications. The relays require a minimal amount of LED
drive current to operate, making it ideal for battery powered
and power consumption sensitive applications. The relay is
constructed using a GaAIAs LED for actuation control and
MOSFET switches for the output. In addition, the relay
employs current-limiting circuitry to provide overvoltage
protection.
APPLICATIONS
• General telecom switching
• Battery powered switch applications
• Instrumentation
• Industrial controls
AGENCY APPROVALS
• UL1577, file no. E52744
ORDERING INFORMATION
L
H
1
5
2
6
A
ELECTR.
VARIATION
#
#
T
R
DIP
SMD
PART NUMBER
PACKAGE
CONFIG.
TAPE AND
REEL
UL
LH1526AAC
7.62 mm
> 0.1 mm
PACKAGE
SMD-8, tube
SMD-8, tape and reel
DIP-8, tube
LH1526AACTR
LH1526AB
Rev. 2.0, 05-Jul-2018
Document Number: 83825
1
For technical questions, contact:
optocoupleranswers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
LH1526AB, LH1526AAC, LH1526AACTR
www.vishay.com
Vishay Semiconductors
ABSOLUTE MAXIMUM RATINGS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
INPUT
IRED continuous forward current
IRED reverse voltage
Input power dissipation
OUTPUT
DC or peak AC load voltage
Continuous DC load current at 25 °C,
one channel
Continuous DC load current at 25 °C,
two channels
SSR output power dissipation
SSR
Ambient temperature range
Storage temperature range
Soldering temperature
t = 10 s max.
T
amb
T
stg
T
sld
-40 to +85
-40 to +150
260
°C
°C
°C
V
L
I
L
I
L
P
diss
400
125
100
550
V
mA
mA
mW
I
F
V
R
P
diss
50
5
80
mA
V
mW
CONDITIONS
SYMBOL
VALUE
UNIT
Note
• Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. Functional operation of the device is not
implied at these or any other conditions in excess of those given in the operational sections of this document. Exposure to absolute
maximum ratings for extended periods of the time can adversely affect reliability
ELECTRICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
INPUT
IRED forward current, switch turn-on
IRED forward current, switch turn-off
IRED forward voltage
IRED reverse current
OUTPUT
On-resistance
Off-resistance
Off-state leakage current
Output capacitance
Current limit AC/DC
TRANSFER
Capacitance (input to output)
V
IO
= 1 V
C
IO
-
1
-
pF
Note
• Minimum and maximum values are testing requirements. Typical values are characteristics of the device and are the result of engineering
evaluations. Typical values are for information only and are not part of the testing requirements
I
F
= 1.5 mA, I
L
= 50 mA
I
F
= 0 mA, V
L
= ± 100 V
I
F
= 0 mA, V
L
= ± 100 V
I
F
= 0 mA, V
L
= ± 350 V
I
F
= 0 mA, V
L
= 1 V, 1 MHz
I
F
= 0 mA, V
L
= 50 V, 1 MHz
I
F
= 1.5 mA, t = 5 ms, V
L
= ± 6 V
R
ON
R
OFF
I
O
I
O
C
O
C
O
I
limit
-
-
-
-
-
-
170
22
5000
<1
6
39
6
300
36
-
200
1000
-
-
450
Ω
GΩ
nA
nA
pF
pF
mA
I
L
= 100 mA, t = 10 ms
V
L
= ± 350 V
I
F
= 1.5 mA
V
R
= 5 V
I
Fon
I
Foff
V
F
I
R
-
0.001
0.80
-
0.25
0.150
1.28
-
0.5
-
1.40
10
mA
mA
V
μA
TEST CONDITION
SYMBOL
MIN.
TYP.
MAX.
UNIT
SWITCHING CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Turn-on time
Turn-off time
TEST CONDITION
I
F
= 1.5 mA, I
L
= 50 mA
I
F
= 5 mA, I
L
= 50 mA
I
F
= 1.5 mA, I
L
= 50 mA
I
F
= 5 mA, I
L
= 50 mA
SYMBOL
t
on
t
on
t
off
t
off
MIN.
-
-
-
-
TYP.
0.5
0.13
0.05
0.05
MAX.
-
1
-
1.5
UNIT
ms
ms
ms
ms
Rev. 2.0, 05-Jul-2018
Document Number: 83825
2
For technical questions, contact:
optocoupleranswers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
LH1526AB, LH1526AAC, LH1526AACTR
www.vishay.com
Vishay Semiconductors
Input
A
V
L
90 %
10 %
t
on
t
off
C
Output
Output
Fig. 1 - Timing Schematic
SAFETY AND INSULATION RATINGS
PARAMETER
Climatic classification
Pollution degree
Comparative tracking index
Maximum rated withstanding isolation voltage
Maximum transient isolation voltage
Maximum repetitive peak isolation voltage
Isolation resistance
Output safety power
Input safety current
Safety temperature
Creepage distance
Clearance distance
Insulation thickness
Input to output test voltage, method B
Input to output test voltage, method A
V
IORM
x 1.875 = V
PR
, 100 % production test
with t
M
= 1 s, partial discharge < 5 pC
V
IORM
x 1.6 = V
PR
, 100 % sample test
with t
M
= 10 s, partial discharge < 5 pC
DTI
V
PR
V
PR
TEST CONDITION
According to IEC 68 part 1
According to DIN VDE 0109
Insulation group IIIa
According to UL1577, t = 1 min
According to DIN EN 60747-5-5
According to DIN EN 60747-5-5
V
IO
= 500 V, T
amb
= 25 °C
V
IO
= 500 V, T
amb
= 100 °C
CTI
V
ISO
V
IOTM
V
IORM
R
IO
R
IO
P
SO
I
SI
T
S
SYMBOL
VALUE
40 / 85 / 21
2
175
5300
8000
890
≥
10
12
≥
10
11
600
240
175
≥
7
≥
7
≥
0.4
1669
1424
V
RMS
V
peak
V
peak
Ω
Ω
mW
mA
°C
mm
mm
mm
V
peak
V
peak
UNIT
Note
• As per IEC 60747-5-5, § 7.4.3.8.2, this optocoupler is suitable for “safe electrical insulation” only within the safety ratings. Compliance with
the safety ratings shall be ensured by means of protective circuits.
800
300
P
SO
- Output
Safety
Power (mW)
I
SI
-
Safety
Input Current (mA)
250
200
150
100
50
0
Two channels
One channel
600
One channel
400
200
Two channels
0
-50
0
50
100
150
-50
0
50
100
150
T
amb
- Ambient Temperature (°C)
T
amb
- Ambient Temperature (°C)
Fig. 2 - Safety Power Dissipation vs. Ambient Temperature
Rev. 2.0, 05-Jul-2018
Fig. 3 - Safety Input Current vs. Ambient Temperature
Document Number: 83825
3
For technical questions, contact:
optocoupleranswers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
LH1526AB, LH1526AAC, LH1526AACTR
www.vishay.com
Vishay Semiconductors
TYPICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
2.5
160
140
Normalized Forward Current
for
Switch
Turn-On
One channel
I
L
= 100 mA
2.0
1.5
1.0
0.5
Normalized to T
amb
= 25 °C
0
-40
-20
0
20
40
60
80
100
I
L
- Load Current (mA)
120
100
80
60
40
20
I
F
> 5 mA
0
-40
-20
0
20
40
60
80
100
Two channels
T
amb
- Ambient Temperature (°C)
T
amb
- Ambient Temperature (°C)
Fig. 7 - Normalized Forward Current for Switch Turn-On vs.
Ambient Temperature
Fig. 4 - Maximum Load Current vs. Ambient Temperature
2.0
1.7
V
F
- Forward Voltage (V)
1.6
1.5
1.4
1.3
1.2
1.1
1.0
-40
-20
0
20
40
60
80
100
I
F
= 2 mA
I
F
= 5 mA
I
F
= 10 mA
Normalized On-Resistance
1.5
I
F
= 5.0 mA
I
L
= 50 mA
1.0
0.5
Normalized to T
amb
= 25 °C
0
-40
-20
0
20
40
60
80
100
T
amb
- Ambient Temperature (°C)
Fig. 5 - Forward Voltage vs. Ambient Temperature
T
amb
- Ambient Temperature (°C)
Fig. 8 - Normalized On-Resistance vs. Ambient Temperature
60
60
I
F
- Forward Current (mA)
T = 85 °C
40
T = 25 °C
30
20
10
0
0
0.5
1.0
1.5
2.0
T = -40 °C
C
O
- Output Capacitance (pF)
50
50
40
30
20
10
0
0
I
F
= 0 mA
f = 1 MHz
10
20
30
40
50
60
V
F
- Forward Voltage (V)
Fig. 6 - Forward Current vs. Forward Voltage
V
L
- Load Voltage (V)
Fig. 9 - Output Capacitance vs. Load Voltage
Rev. 2.0, 05-Jul-2018
Document Number: 83825
4
For technical questions, contact:
optocoupleranswers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
LH1526AB, LH1526AAC, LH1526AACTR
www.vishay.com
Vishay Semiconductors
0.20
100
Off-State Leakage Current (nA)
I
F
= 0 mA
T = 85 °C
I
L
= 50 mA
0.16
T = 85 °C
Turn-Off Time (ms)
10
T = 25 °C
1
0.12
T = 25 °C
0.08
T = -40 °C
0.04
0
0.1
T = -40 °C
0.01
0
100
200
300
0
10
20
30
40
50
V
L
- Load Voltage (V)
Fig. 10 - Off-State Leakage Current vs. Load Voltage
I
F
- Forward Current (mA)
Fig. 13 - Turn-Off Time vs. Forward Current
2.0
I
L
= 50 mA
2.0
Normalized Turn-Off Time
1.8
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0
-40
Normalized to T
amb
= 25 °C
-20
0
20
40
60
80
100
I
F
= 5.0 mA
Turn-On Time (ms)
1.5
T = 85 °C
1.0
T = 25 °C
0.5
T = -40 °C
0
0
10
20
30
40
50
I
F
- Forward Current (mA)
Fig. 11 - Turn-On Time vs. Forward Current
T
amb
- Ambient Temperature (°C)
Fig. 14 - Normalized Turn-Off Time vs. Ambient Temperature
2.0
Normalized Turn-On Time
1.8
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0
-40
-20
0
20
40
60
80
100
Normalized to T
amb
= 25 °C
I
F
= 5 mA
T
amb
- Ambient Temperature (°C)
Fig. 12 - Normalized Turn-On Time vs. Ambient Temperature
Rev. 2.0, 05-Jul-2018
Document Number: 83825
5
For technical questions, contact:
optocoupleranswers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
京公网安备 11010802033920号
EEWORLD
