Ordering number : ENA0799
SBT80-10GS
SANYO Semiconductors
DATA SHEET
SBT80-10GS
Applications
•
Schottky Barrier Diode (Twin Type
•
Cathode Common)
100V, 8A Rectifier
High frequency rectification (switching regulators, converters, choppers)
Features
•
•
•
Guaranteed up to Tj=150°C
Short reverse recovery time
High reliability due to highly reliable planar structure
•
•
Low forward voltage (VF max=0.80V)
Low switching noise
Specifications
Absolute Maximum Ratings
at Ta=25°C
Parameter
Repetitive Peak Reverse Voltage
Nonrepetitive Peak Reverse Surge Voltage
Average Output Current
Surge Forward Current
Junction Temperature
Storage Temperature
Symbol
VRRM
VRSM
I
O
I
FSM
Tj
Tstg
50Hz resistive load, sine wave Tc=86°C
50Hz sine wave, 1 cycle
Conditions
Ratings
100
105
8
60
-
-55 to +150
-
-55 to +150
Unit
V
V
A
A
°C
°C
Package Dimensions
unit : mm (typ)
7530-002
10.2
2.7
3.6
4.5
1.3
6.3
Product & Package Information
• Package
: TO-220(LS)
• JEITA, JEDEC
: SC-46, TO-220AB
• Minimum Packing Quantity : 100 pcs./bag, 50 pcs./magazine
Marking
Electrical Connection
1
3
14.0
15.1
SBT
80-10
LOT No.
(1.6)
1.2
14.0
2
0.4
0.8
1
2.55
2
3
2.55
1 : Anode
2 : Cathode
3 : Anode
SANYO : TO-220(LS)
2.55
2.55
2.7
http://semicon.sanyo.com/en/network
63010SD TK IM TC-00002374 No. A0799-1/3
SBT80-10GS
Current waveform 50Hz sine wave
70
Transient Thermal Resistance, Rth(j-c) --
°C
/ W
80
IFSM -- t
I
S
10
7
5
Rth(j-c) -- t
Surge Forward Current, IFSM(Peak) -- A
60
50
40
30
20
10
0
20ms
t
3
2
1.0
7
5
3
0.001 2 3 5 7 0.01 2 3
7 0.01
2
3
5
7 0.1
2
3
5
7 1.0
2
3
5 7 0.1
2 3
5 7 1.0
2 3
Time, t -- s
ID01025
Time, t -- s
5 7 10 2
IT12077
