DG506B, DG507B
Vishay Siliconix
Precision 16-Channel/Dual 8-Channel CMOS Analog Multiplexers
DESCRIPTION
The DG506B and DG507B are high performance analog
multiplexers. Their ultra-low switch charge injection, low
channel capacitance, and low leakage level allows them to
achieve superior switching performance. The DG506B is a
16-channel single-ended analog multiplexer designed to
connect one of sixteen inputs to a common output as
determined by a 4-bit binary address (A0, A1, A2, A3). The
DG507B is a dual 8-channel differential analog multiplexer
designed to connect one of eight differential inputs to a
common dual output as determined by its 3-bit binary
address (A0, A1, A2). Break-before-make switching action
protects against momentary crosstalk between adjacent
channels.
An on channel conducts current equally well in both
directions. In the off state each channel blocks voltages up to
the power supply rails. An enable (EN) function allows the
user to reset the multiplexer/demultiplexer to all switches off
for stacking several devices. All control inputs, addresses
(Ax) and enable (EN) are TTL compatible over the full
specified operating temperature range.
The DG506B and DG507B are fabricated on an enhanced
SG-II CMOS process that achieves improved performance
on: reduced charge injection, lower device leakage, and
minimized parasitic capacitance.
As the DG506, DG507 has a long history in the industry with
many suppliers offering copies, and in some cases improved
variations, with the best in class improvements, the Vishay
Siliconix new version of the DG506B, DG507B are the
superior alternatives to what is currently available.
Applications for the DG506B, DG507B include high speed
and high precision data acquisition, audio signal switching
and routing, ATE systems, and avionics. High performance
and low power dissipation make them ideal for battery
operated and remote instrumentation applications.
The DG506B and DG507B have the absolute maximum
voltage rating extended to 44 V. Additionally, single supply
operation is also allowed. An epitaxial layer prevents
latch-up.
The DG506B and DG507B are both available in 28-lead
SOIC and TSSOP package options with extended
temperature range of -40 °C to +125 °C.
For more information, refer to Vishay Siliconix DG506B,
DG507B evaluation board note.
FEATURES
• Operate with single or dual power supply
• V+ to V- analog signal swing range
• 44 V power supply maximum rating
• Extended operate temperature range:
-40 °C to +125 °C
• Low leakage typically < 3 pA
• Low charge injection - Q
INJ
= 1 pC
• Low power - I
SUPPLY
: 5 µA
• TTL compatible logic
• > 250 mA latch up current per JESD78
• Available in SOIC28 and TSSOP28 packages
• Superior alternative to:
- ADG506A, DG506A, HI-506
- ADG507A, DG507A, HI-507
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
BENEFITS
• Reduced switching errors
• Reduced glitching
• Improved data throughput
• Reduced power consumption
• Increased ruggedness
• Wide supply ranges (± 5 V to ± 20 V)
APPLICATIONS
• Data acquisition systems
• Audio and video signal routing
• ATE systems
• Medical instrumentation
Document Number: 65150
S13-2567-Rev. C, 16-Dec-13
For technical questions, contact:
analogswitchtechsupport@vishay.com
www.vishay.com
1
This document is subject to change without notice.
THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
DG506B, DG507B
Vishay Siliconix
TRUTH TABLE
DG506B
A
3
X
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
1
A
2
X
0
0
0
0
1
1
1
1
0
0
0
0
1
1
1
1
A
1
X
0
0
1
1
0
0
1
1
0
0
1
1
0
0
1
1
A
0
X
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
EN
0
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
On Switch
None
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
TRUTH TABLE
DG507B
A
2
X
0
0
0
0
1
1
1
1
A
1
X
0
0
1
1
0
0
1
1
A
0
X
0
1
0
1
0
1
0
1
EN
0
1
1
1
1
1
1
1
1
On Switch
None
1
2
3
4
5
6
7
8
Logic “0” = V
IL
0.8
V
Logic “1” = V
IH
2.4
V
X = Do not care
ORDERING INFORMATION
DG506B
Temp. Range
Package
28-Pin SOIC
-40 °C to 125 °C
28-Pin TSSOP
28-Pin PLCC
Part Number
DG506BEW-T1-GE3
DG506BEQ-T1-GE3
DG506BEN-T1-GE3
ORDERING INFORMATION
DG507B
Temp. Range
Package
28-Pin SOIC
-40 °C to 125 °C
28-Pin TSSOP
28-Pin PLCC
Part Number
DG507BEW-T1-GE3
DG507BEQ-T1-GE3
DG507BEN-T1-GE3
ABSOLUTE MAXIMUM RATINGS
Parameter
Voltages Referenced to V-
Digital
Inputs
a
, V
S
, V
D
V+
GND
Limit
44
25
(V-) - 2 to (V+) + 2
or 20 mA, whichever occurs first
30
100
-65 to 150
c
Unit
V
Current (Any terminal)
Peak Current, S or D (Pulsed at 1 ms, 10 % duty cycle max.)
Storage Temperature
Power Dissipation (Packages)
b
mA
°C
mW
(EW, EQ, EN suffix)
28-Pin Wide Body SOIC
28-Pin TSSOP
d
28-Pin PLCC
e
c
840
817
1693
95.3
97.9
47.3
°C/W
28-Pin Wide Body SOIC
Thermal Resistance (
J-A
)
b
28-Pin TSSOP
d
28-Pin PLCC
e
Notes:
a. Signals on S
X
, D
X
or IN
X
exceeding V+ or V- will be clamped by internal diodes. Limit forward diode current to maximum current ratings.
b. All leads soldered or welded to PC board.
c. Derate 10.5 mW/°C above 70 °C.
d. Derate 10.2 mW/°C above 70 °C.
e. Derate 21.2 mW/°C above 70 °C.
Document Number: 65150
S13-2567-Rev. C, 16-Dec-13
For technical questions, contact:
analogswitchtechsupport@vishay.com
www.vishay.com
3
This document is subject to change without notice.
THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
