BIMD58G1P24B13/16KAD: DescriptionRotary Position Encoder; CategoryLED optoelectronic/LED photoelectric; File Size123KB，2 Pages; ManufacturerBaumer Electric Ag

Download Datasheet Parametric Compare View All

BIMD58G1P24B13/16KAD Overview

Rotary Position Encoder

BIMD58G1P24B13/16KAD Parametric

Parameter Name	Attribute value
Maker	Baumer Electric Ag
Reach Compliance Code	unknown
Maximum operating temperature	85 °C
Minimum operating temperature	-20 °C
Optoelectronic device types	ROTARY POSITION ENCODER

Preview

Download Datasheet

View All

Absolute multi-turn hollow shaft encoder

BIMD ﬂexible

Proﬁbus-DP, CANopen, DeviceNet

features

• interface: Proﬁbus-DP, CANopen, DeviceNet

• resolution 13 bit single-turn

• resolution 16 bit multi-turn

• programmable operating modes

• programmable resolution and preset values

• hollow shaft ø 14 mm

• compact housing

general data

voltage supply

max. current supply

no load

signal code

max. resolution

single-turn

multi-turn

max. error limit

preset

address

baud rate

direction of rotation

10 - 30 VDC

with reverse polarity protection

100 mA (at 24 VDC)

shaft

order designation

BIMD 58

1P24C13/16

base encoder

without bus cover

binary

13 bit (1 step = 2' 38")

16 bit (65'536 rev.)

±0,025°

value programmable within

resolution range

selectable via dip switches

looking at the ﬂange, position

counts up as the shaft rotates

clockwise (CW), programmable

BIMD 58

through hollow shaft 12 mm

through hollow shaft 14 mm

max. switching frequency 800 kHz

with torque pin

13/16

complete encoder

shaft

through hollow shaft 12 mm

through hollow shaft 14 mm

mechanical data

max. revolutions

moment of inertia

max. protection class

material

weight

ambient conditions

temperature range

relative humidity

vibration

shock

noise immunity

emitted interference

-20...+85 °C

max. 95%

non condensing

DIN EN 60068-2-6

(< 100 m/s

/ 16-2'000 Hz)

DIN EN 60068-2-27

(< 2'000 m/s

/ 6 ms)

DIN EN 61000-6-2

DIN EN 61000-6-4

Other versions on request.

accessories

CD-ROM with GSD-/ESD-/XML-

ﬁles and manuals

spring plate for use

with torque pin

part nr. 147362

part nr. 140347

6'000 rpm

200 x 10 kgm

IP 54

housing: aluminum

approx. 600 g

with torque pin

-6

interface

24B

CANopen

24D

DeviceNet

24P

Proﬁbus

3. 34

www.baumerelectric.com
