Kotron
®
RF Point
Level Switches
D E S C R I P T I O N
Kotron RF Capacitance Level Switches offer the industrial
user a choice of alarm and control configurations. This
amplifier utilizes extremely high radio frequency
circuitry to minimize the effect of media build-up on the
sensing probe.
F E A T U R E S
•
Models available for single point narrow differential
(alarm) and single point wide differential (pump control)
•
Integral or remote mount models allowing up to
5000 feet (1500 meters) between probe and electronics
•
User selectable fail-safe switch
•
Remote configurations available for high process
temperature
•
High/low range selector allows for accurate calibration
on both long and short length sensing probes, in both
conductive and non-conductive media
•
Wide calibration range
•
Probe lengths from 6 inches (150 mm) minimum to
150 feet (45 meters) maximum
•
0–3 second adjustable time delay (rising level), on
narrow differential models, prevents relay chatter in tur-
bulent applications
•
Available with a full range of rigid and flexible sensing
probes to +1000° F (+538° C) and 5000 psig (345 bar)
A P P L I C A T I O N S
•
Clean or dirty liquids
•
Viscous liquids
•
Light slurries
•
Corrosive liquids
•
High temperature/pressure liquids
•
Chemicals
•
Hydrocarbons and solvents
•
Acids and salts
•
Foods and beverages
T E C H N O L O G Y
The amount of capacitance developed in any vessel is
determined by the size (surface area) of the probe, the
distance from the probe to its ground, and the dielectric
of the medium being measured. Considering that the
probe’s mounting position is fixed, and that the dielectric
value of the medium is constant, then the amount of
capacitance developed in any vessel becomes dependent
upon the amount of the probe which is covered by the
media.
As media rises and falls in the tank, the amount of capaci-
tance developed between the sensing probe and the
ground also rises and falls. This change in capacitance is
sensed by the electronics.
The capacitance-controlled oscillator circuit, mounted on
the probe, changes the capacitance signal to a variable
frequency. This stabilized signal can then be sent to the
main electronics located up to 5000 feet (1500 meters)
away via standard shielded, twisted pair cable. Using stan-
dard twisted pair cable eliminates the costly coaxial or
triaxial cable utilized by other manufacturers which limits
the installation to 150 feet (45 meters) maximum distance
.
M O D E L
N U M B E R
Note:
Delivery is ESP only if Model 80/81
and probe selected are both ESP.
Models available for quick shipment, usually within one week after factory
receipt of a purchase order, through the Expedite Ship Plan (ESP).
MOUNTING
80
81
Integral
Remote
HOUSING
52
80
NEMA 4X, carbon steel,
3
⁄
4
" NPT single conduit
NEMA 4X/7/9, aluminum
,
3
⁄
4
" NPT dual conduit
TYPE
12
22
Single set point for alarm control with narrow differential
Single set point for pump control with wide differential
INPUT POWER
0
1
2
120 VAC
240 VAC
24 VDC
8
3
2
P R O B E S
A full range of rigid and flexible probes for conductive
and non-conductive materials is available in various
lengths and materials of construction. For further
information on probe assemblies, refer to bulletin 50-125.
C A B L E
Connecting cable should be shielded, twisted pair,
22-gauge stranded conductors and may be ordered
using Magnetrol part number 009-7146-XXX
(where XXX = length in feet). 10 feet (3 meters) min.,
5000 feet (1500 meters) max. length. For lengths over
999 feet, use X009-7146-999 where X=total length in feet.
2
A G E N C Y
AGENCY
FM
A P P R O V A L S
Class
I,
Div. 1, Groups C & D
Class
II,
Div. 1, Groups E, F & G
Note: This approval available
with rigid insulated
probes only
Non-hazardous environments:
NEMA 4X
Class
I,
Groups C & D
Class
II,
Groups E, F & G
TYPE 4X
(This approval excludes use
with bare probes)
Non-hazardous locations:
TYPE 4X
S P E C I F I C A T I O N S
Supply voltage
120 VAC, 50–60 Hz (+10%, -15%)
240 VAC, 50–60 Hz (+10%, -15%)
24 VDC (±10%)
3 watts maximum
0 pF minimum, 3000 pF maximum
High range: 4 pF minimum
1500 pF maximum
Low range:
Fixed minimum differential
(narrow differential)
Output relays (DPDT)
Time delay (narrow differential)
Response time
Ambient temperature
at electronics
Operating pressure/
temperature
2 pF minimum
500 pF maximum
MODEL
8X-80XX-3XX
APPROVAL
Power consumption
Zero range
Differential range
(wide differential)
All models
CSA
8X-80XX-3XX
0.5 pF minimum
AC: 10 amp @ 120/240 VAC resistive
DC: 10 amp @ 24 VDC resistive
0–3 seconds
100 milliseconds
-40° to +160° F
(-40° to +71° C)
Dependent upon probe selection;
refer to probe bulletin 50-125
All models
Temperature coefficient of output
-40° to +160° F
+0.02 pF per degree F
(-40° to +71° C)
(+0.036 pF per degree C)
D I M E N S I O N A L
I N C H E S
( m m )
S P E C I F I C A T I O N S
1
Rotation
B
A
B
A
clearance
Rotation clearance
2.63 (66)
Rotation clearance
3.00 (76)
C
G
E
G
3/4" NPT
Conduit
connection
Plugged
Optional
mounting
flange
F
7.42
(188)
D
Optional
mounting
flange
I.L.
3.00
(76)
2.37
(60)
3.75
(95)
1/2" NPT (opt.)
3/4" NPT (std.)
Transducer/Amplifier
cable connection
2 Holes
.38 (10)
diameter
2.00
(51)
4.87
(124)
1.25
(32)
.1875 (5)
.2500 (6)
2.95
5.50
(75)
(141)
.75
(19)
Optional
Weight
P/N 004-4355-001
.50 (13)
.625 (16)
3.50
(89)
Optional Anchor
Assembly
P/N 032-8814-001
Integral Mount with Rigid Probe
NEMA 4X housing,
3
⁄
4
" NPT single conduit
Remote Mount with Flexible Probe
NEMA 4X/7/9 housing,
3
⁄
4
" NPT dual conduit
Standard Rigid Probe
Housing
NEMA 4X
Carbon steel
NEMA 4X/7/9
Aluminum
A
3.38
(86)
5.25
(133)
B
4.69
(119)
5.81
(148)
C
9.04
(230)
11.26
(286)
D
2.29
(58)
2.40
(61)
E
11.67
(296)
13.81
(351)
F
4.04
(103)
4.15
(105)
C
10.48
(266)
12.70
(323)
Flexible Probe
D
3.73
(95)
4.67
(119)
E
11.67
(296)
13.81
(3.51)
F
4.04
(103)
4.15
(105)
Conduit Connection
G
⁄
4
" NPT
single conduit
3
⁄
4
" NPT
dual conduit
3
3
Q U A L I T Y
The quality assurance system in place at
Magnetrol guarantees the highest level of
quality throughout the company. Magnetrol
is committed to providing full customer
satisfaction both in quality products and
quality service.
Magnetrol’s quality assurance system is regis-
tered to ISO 9001 affirming its commitment
to known international quality standards
providing the strongest assurance of product
and service quality available.
E S P
Several Kotron RF Point Switches are avail-
able for quick shipment, usually within one
week after factory receipt of a purchase
order, through the Expedite Ship Plan (ESP).
To take advantage of ESP, simply match the
color coded model number codes (standard
dimensions apply).
ESP service may not apply to orders of ten
units or more. Contact your local representa-
tive for lead times on larger volume orders,
as well as other products and options.
E
xpedite
S
hip
P
lan
W A R R A N T Y
All Magnetrol electronic level and flow
controls are warranted free of defects in
materials or workmanship for one full year
from the date of original factory shipment.
If returned within the warranty period; and,
upon factory inspection of the control, the
cause of the claim is determined to be cov-
ered under the warranty; then, Magnetrol
will repair or replace the control at no cost
to the purchaser (or owner) other than
transportation.
Magnetrol shall not be liable for misapplica-
tion, labor claims, direct or consequential
damage or expense arising from the installa-
tion or use of equipment. There are no other
warranties expressed or implied, except
special written warranties covering some
Magnetrol products.
For additional information, see Instruction Manual 50-605.
5300 Belmont Road • Downers Grove, Illinois 60515-4499 • 630-969-4000 • Fax 630-969-9489 • www.magnetrol.com
145 Jardin Drive, Units 1 & 2 • Concord, Ontario Canada L4K 1X7 • 905-738-9600 • Fax 905-738-1306
Heikensstraat 6 • B 9240 Zele, Belgium • 052 45.11.11 • Fax 052 45.09.93
Regent Business Ct r., Jubilee Rd. • Burgess Hill, Sussex RH15 9TL U.K. • 01444-871313 • Fax 01444-871317
Copyright © 2008 Magnetrol International, Incorporated. All rights reserved. Printed in the USA.
Performance specifications are effective with date of issue and are subject to change without notice.
BULLETIN: 50-135.13
EFFECTIVE: April 2008
SUPERSEDES: April 2001
