MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS
BXF
BXF
SERIES
Load Life : 105℃ 10000 hours.
◆FEATURES
・
20mm height Max.
・
High Ripple Current.
・
Electronic Ballast, Power Supply.
For
・
RoHS compliance.
◆SPECIFICATIONS
Items
Category Temperature Range
Characteristics
−25∼＋105℃
160∼450V.DC
±20％
（20℃，
120Hz）
I＝0.04CV+100μA
(After 1 minute application of rated voltage)
I＝0.02CV+25μA
(After 5 minutes application of rated voltage)
Rated Voltage Range
Capacitance Tolerance
Leakage Current(MAX)
I＝(μA)
Leakage Current
C＝(μF)
Rated Capacitance
V＝(V)
Rated Voltage
(tanδ)
Dissipation Factor(MAX)
Rated Voltage 160 200 250 350 400 450
tanδ
0.15 0.15 0.15 0.20 0.20 0.20
（20℃，
120Hz）
After applying rated voltage with rated ripple current for 10000 hours at 105℃,
the capacitors shall meet the following requirement.
Capacitance Change
Dissipation Factor
Leakage Current
Within ±25％ of the initial value.
Not more than 200％ of the specified value.
Not more than the specified value.
Endurance
Low Temperature Stability
Impedance Ratio(MAX)
Rated Voltage
160 200 250 350 400 450
3
3
6
6
6
（120Hz）
Z
（−25℃） （20℃） 3
/Z
◆MULTIPLIER FOR RIPPLE CURRENT
Frequency Coefficient
Frequency
◆OPTION
Code
（Hz）
120
1k
10k 100k≦
0.90 1.00
0.90 1.00
0.90 1.00
PET Sleeve
Blank
10∼18μF
Coefficient
0.30 0.60
0.40 0.70
22∼82μF
100∼220μF 0.45 0.75
◆PART NUMBER
□□□
Rated Voltage
BXF
Series
□□□□□
Rated Capacitance
M
Capacitance Tolerance
□□□
Option
□□
Lead Forming
D×L
Case Size
MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS
BXF
(mm)
◆DIMENSIONS
SLEEVE(PET)
±0.5
φd
φD
φd
F
10 12.5 16
0.6
5.0
18
F
0.8
7.5
L＋2MAX
15MIN
4MIN
φD＋0.5MAX
◆STANDARD SIZE
WV
（V.DC）
Cap(μF)
47
68
82
160
(2C)
100
100
180
220
33
47
200
(2D)
56
68
82
120
180
27
39
47
250
(2E)
56
56
100
120
Size
10×16
10×20
16×16
12.5×20
18×16
16×20
18×20
10×16
10×20
16×16
12.5×20
18×16
16×20
18×20
10×16
10×20
16×16
12.5×20
18×16
16×20
18×20
Ripple
650
800
1350
1350
1550
1800
2250
650
800
1350
1350
1550
1800
2250
650
800
1350
1350
1550
1800
2250
Size φD×L(mm), Ripple Current (mA r.m.s./105℃, 100kHz)
WV
（V.DC）
Cap(μF)
18
22
27
350
(2V)
33
33
56
82
12
18
400
(2G)
18
27
27
47
56
10
15
15
450
(2W)
22
22
33
47
Size
10×16
10×20
16×16
12.5×20
18×16
16×20
18×20
10×16
10×20
16×16
12.5×20
18×16
16×20
18×20
10×16
10×20
16×16
12.5×20
18×16
16×20
18×20
Ripple
450
500
780
850
960
1200
1300
450
500
780
850
960
1200
1300
350
400
700
700
850
970
1170
